Huba Control Differential Pressure Transmitter 692.918001161

Get a Price/Quote

MOQ : 10 Pieces

Huba Control Differential Pressure Transmitter 692.918001161 Specification

Material
Stainless Steel

Usage
petrochemical, Petrochemical Industry, lab-tool-1, Chemical Industry, treatment-1, Water Treatment PlantsIndustry, textile-1, Textile Industry, Food & Beverages, Refineries, Nuclear Power, Power plant, fertilizers, paper Mills, Oil & Gas, Mining, Steel Plant, Boilers,

Processing Type
Standard

Product Type
Huba Control Differential Pressure Transmitter 692.918001161

Weight
430 Grams (g)

Color
Red

Mount Type
Panel

Scale Range
0-4 Bar

Accuracy
< 0.5 %

Huba Control Differential Pressure Transmitter 692.918001161 Trade Information

Minimum Order Quantity
10 Pieces

FOB Port
Delhi

Payment Terms
Cash Against Delivery (CAD), Paypal, Cash Advance (CA), Cash in Advance (CID), Cash on Delivery (COD)

Supply Ability
4 Pieces Per Week

Delivery Time
4 Week

Main Export Market(s)
Asia, Middle East

Main Domestic Market
All India

About Huba Control Differential Pressure Transmitter 692.918001161

Huba Control Differential Pressure Transmitter 692.918001161

Brand : Huba Control

Model : 692.918001161

Range : 0-4 Bar

Type : 692 0-4 Bar

Current Out : 0-10 VDC / 24 VAC A15 %

IN - 18-33 VDC

Made In Switzerland

Huba Control Differential Pressure Transmitter 692
Product InformationDifferential pressure transmitter 692
The Pressure Transmitters of Type 692 Feature The Unique And Proven Ceramic Technology. Depending On The Application, Various Pressure Connections And Electrical Connections With Standardized Output Signals Are Available. Due To The Wide Variety Of Options,The Transmitters 692 Are Suitable For All Types Of Industrial Applications.

Very Low Temperature Sensitivity

High Temperature Resistance

No Mechanical Creep

Individual Applications Through Modular System And Different Material Choices

Technical DataProduct Feature

Pressure Measuring Range : 0 ... 25 Bar (Relative And Difference)

Response Time : <5 ms

Load Change : <50 Hz

Sensor Weight : 430 g

Field Of Application

Media : Process Medium; Gas

Medium Temperature : -15 ... 85 AC

Permissible Overload On One Side : See Variant Plan

System Pressure : 12; 25; 50 Bar

Bursting Pressure : 1.5 x System Pressure

Ambient Condition

Ambient Temperature : -15 ... 85 AC

Storage Temperature : -40 ... 85 AC

Material

Housing : Stainless Steel 1.4305 (AISI 303); PVDF

Pressure Connection With Media Contact : Stainless Steel 1.4305 (AISI 303); PVDF; CuZn Vni

Measuring Element With Media Contact : Ceramic Al2O3 (96 %)

Sealing Material With Media Contact : FPM; EDPM; NBR; MVQ; CR

Electrical Data

Current Consumption : <20 mA

Inverse-Polarity Protection : Short-Circuit And Reverse Polarity Protected. Each Connection Against Each Other With Max. Supply Voltage.

Installation Guide

Installation Orientation : any

Assembly : Mounting Bracket

Approval
EMC Compatibility : CE-Compliant In Accordance With EN 61326-2-3
Applications

REFRIGERATION SYSTEMS

CPU

WATER PUMPS

ULTRAFILTRATION SYSTEM

Accessories

Mounting Bracket

Socket Outlet DIN EN 175301-803-A : With Seal; IP 65, When Mounted And Screwed.

Socket Outlet DIN EN 60130-9 : IP 65, When Mounted And Screwed.

Calibration Certificate

Unmatched Accuracy and Durability

Engineered with high-precision technology, the Huba Control Differential Pressure Transmitter ensures accurate readings within a 0.5% error margin. Crafted from stainless steel, it withstands harsh environments, making it ideal for various applications across the petrochemical, chemical, water treatment, textile, and energy sectors.

Versatile Industrial Applications

This transmitter's wide measurement range and robust build allow it to handle the differential pressure of steam, oil, and gas across refineries, power plants, food & beverage plants, and more. Its panel mounting capability simplifies integration into new or existing systems.

Exceptional Finishing Options

Available in antique, polished, galvanized, and matte finishes, the transmitter not only guarantees operational reliability but also complements the aesthetics of your facility. At just 430g, installation and maintenance are straightforward, offering efficiency and flexibility.

FAQ's of Huba Control Differential Pressure Transmitter 692.918001161:

Q: How does the Huba Control Differential Pressure Transmitter 692.918001161 enhance process monitoring in industrial settings?
A: This transmitter accurately measures differential pressure up to 4 bar with less than 0.5% error, enabling real-time monitoring and control of processes involving steam, oil, or gas. This ensures safer and optimized operations across various industries.

Q: What materials and finishing options are available for this pressure transmitter?
A: The transmitter is constructed from high-quality stainless steel for enhanced durability and is available in several finishes including antique, polished, galvanized, and matte, catering to both functional and aesthetic preferences.

Q: When should this differential pressure transmitter be used?
A: It is best utilized when precise pressure monitoring is required in demanding environments such as petrochemical plants, water treatment facilities, power stations, textile mills, and other heavy industries.

Q: Where can the Huba Control Differential Pressure Transmitter be installed?
A: Designed for panel mounting, it can be seamlessly integrated into control panels of industrial sites like refineries, water treatment plants, chemical industries, power generation units, and laboratories.

Q: What is the process for installing and maintaining this transmitter?
A: Installation involves panel mounting followed by connection to the relevant pressure lines. Due to its stainless steel build and compact weight, maintenance is minimal, requiring only periodic checks for calibration to ensure continued accuracy.

Q: How does this product benefit users in industries such as mining, steel plants, or power generation?
A: Its reliable performance, robust construction, and accurate measurement capabilities contribute to improved process safety, efficiency, and optimized resource usage, directly benefitting operational outcomes in heavy industries.

Q: What is the typical usage of this transmitter in the food & beverage or textile industry?
A: In food & beverage and textile industries, the device is used to monitor and control critical pressures, maintaining product quality and process integrity within safe operating parameters.
