Huba - Control Differential Pressure Transmitter 692.919007141

Name: Huba - Control Differential Pressure Transmitter 692.919007141
Brand: D. P. ENGINEERS
Price: 35800 INR
Availability: InStock

Price 35800 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

Huba - Control Differential Pressure Transmitter 692.919007141 Specification

Thread
1/4 inch NPT

Usage
REFRIGERATION SYSTEMS,CPU,WATER PUMPS,ULTRAFILTRATION SYSTEM

Material
Stainless Steel

Size
0-6 BAR

Processing Type
Standard

Product Type
Huba - Control Differential Pressure Transmitter 692.919007141

Weight
450 Grams (g)

Mount Type
Back

Color
Red

Scale Range
0-6 BAR

Accuracy
+-0.5 %

Huba - Control Differential Pressure Transmitter 692.919007141 Trade Information

Minimum Order Quantity
10 Pieces

FOB Port
Delhi

Payment Terms
Cash on Delivery (COD), Cash in Advance (CID), Cash Advance (CA), Cash Against Delivery (CAD), Paypal

Supply Ability
4 Pieces Per Week

Delivery Time
4 Week

Main Export Market(s)
Asia, Middle East

Main Domestic Market
All India

Huba - Control Differential Pressure Transmitter 692.919007141 About

Huba - Control Differential Pressure Transmitter 692.919007141

Brand : Huba Control

Model : 692.919007141

Range : 0-6 Bar

Type : 692 0-6 Bar

Current Out : 4-20mA

Voltage - 11-33V DC

Made In Switzerland

Huba Control Differential Pressure Transmitter 692
Product InformationDifferential pressure transmitter 692
The Pressure Transmitters of Type 692 Feature The Unique And Proven Ceramic Technology. Depending On The Application,Various Pressure Connections And Electrical Connections With Standardized Output Signals Are Available.Due To The Wide Variety Of Options,The Transmitters 692 Are Suitable For All Types Of Industrial Applications.

Very Low Temperature Sensitivity

High Temperature Resistance

No Mechanical Creep

Individual Applications Through Modular System And Different Material Choices

Technical DataProduct Feature

Pressure Measuring Range : 0 ... 25 Bar (Relative And Difference)

Response Time : <5 ms

Load Change : <50 Hz

Sensor Weight : 430 g

Field Of Application

Media : Process Medium; Gas

Medium Temperature : -15 ... 85 AC

Permissible Overload On One Side : See Variant Plan

System Pressure : 12; 25; 50 Bar

Bursting Pressure : 1.5 x System Pressure

Ambient Condition

Ambient Temperature : -15 ... 85 AC

Storage Temperature : -40 ... 85 AC

Material

Housing : Stainless Steel 1.4305 (AISI 303); PVDF

Pressure Connection With Media Contact : Stainless Steel 1.4305 (AISI 303); PVDF; CuZn Vni

Measuring Element With Media Contact : Ceramic Al2O3 (96 %)

Sealing Material With Media Contact : FPM; EDPM; NBR; MVQ; CR

Electrical Data

Current Consumption : <20 mA

Inverse-Polarity Protection : Short-Circuit And Reverse Polarity Protected. Each Connection Against Each Other With Max. Supply Voltage.

Installation Guide

Installation Orientation : any

Assembly : Mounting Bracket

Approval
EMC Compatibility : CE-Compliant In Accordance With EN 61326-2-3
Applications

REFRIGERATION SYSTEMS

CPU

WATER PUMPS

ULTRAFILTRATION SYSTEM

Accessories

Mounting Bracket

Socket Outlet DIN EN 175301-803-A : With Seal; IP 65, When Mounted And Screwed.

Socket Outlet DIN EN 60130-9 : IP 65, When Mounted And Screwed.

Calibration Certificate

WhatsApp No.9871014210,WhatsApp No.9811065204,WhatsApp No.8376899729,WhatsApp No.8368888047,WhatsApp No.9268631221,

Precision Measurement for Versatile Applications

Engineered to perform in demanding environments, the Huba 692.919007141 Differential Pressure Transmitter provides accurate, consistent readings across various media including steam, oil, and gas. With a measurement range of 0-6 BAR and 0.5% accuracy, it supports reliable monitoring in refrigeration systems, CPUs, and filtration units.

Durable Construction and Flexible Installation

Fabricated from high-quality stainless steel, this transmitter resists corrosion and mechanical stress, ensuring longevity and stable performance. The 1/4 inch NPT thread and diverse finish options enable straightforward integration and customization to suit system requirements and aesthetic preferences.

FAQ's of Huba - Control Differential Pressure Transmitter 692.919007141:

Q: How is the Huba Control Differential Pressure Transmitter 692.919007141 typically installed?
A: The transmitter is installed using its 1/4 inch NPT threaded connection and back mount configuration, allowing for secure and straightforward integration into existing pipelines or equipment.

Q: What types of pressure does this transmitter measure?
A: This model is suitable for differential pressure measurement of steam, oil, and gas within its 0-6 BAR range, making it versatile for different industrial media.

Q: When should this transmitter be used in a system?
A: It is ideal for use whenever precise differential pressure monitoring is required, particularly in refrigeration systems, CPUs, water pumps, and ultrafiltration processes.

Q: Where can the Huba Differential Pressure Transmitter be applied?
A: It is suitable for any industrial setup requiring accurate pressure control such as HVAC, water treatment, process engineering, and energy systems, especially where reliability and durability are paramount.

Q: What is the process of pressure measurement with this device?
A: The transmitter measures the difference in pressure between two points using its internal sensors and stainless steel body, providing a signal proportional to the pressure difference in the 0-6 BAR range.

Q: How does the device benefit industrial systems?
A: By delivering accurate pressure readings with a 0.5% margin, it enhances process control, reduces system downtime, and promotes energy efficiency in critical industrial operations.

Q: What maintenance is required for optimal functioning?
A: Routine checks for connections, periodic cleaning, and verification against calibrated pressure standards ensure the transmitter maintains its accuracy and extends its working life.
