604.9000002 HUBA CONTROL DIFFERENTIAL PRESSURE SWITCH 0.2-3 Mbar

Price 4800 INR/ Piece

Get a Price/Quote

MOQ : 15 Pieces

604.9000002 HUBA CONTROL DIFFERENTIAL PRESSURE SWITCH 0.2-3 Mbar Specification

Material
Other

Usage
pharmaceutical,Hotel,Malls,Hospital,OT,POWER PLANT,CEMENT PLANT,STEEL PLANT,FERTILIZER,TEXTILE,Pharmaceutical Manufacture,Food And Beverages Industry,Pulp And Paper Industry,Textile Industry

Processing Type
Standard

Product Type
604.9000002 HUBA CONTROL DIFFERENTIAL PRESSURE SWITCH 0.2-3 Mbar

Weight
143 Grams (g)

Mount Type
Back

Color
White

Scale Range
0...50 Mbar

604.9000002 HUBA CONTROL DIFFERENTIAL PRESSURE SWITCH 0.2-3 Mbar Trade Information

Minimum Order Quantity
15 Pieces

FOB Port
Delhi

Payment Terms
Paypal, Cash Against Delivery (CAD), Cash in Advance (CID), Cash Advance (CA), Cash on Delivery (COD)

Supply Ability
1 Piece Per Day

Delivery Time
1 Days

Main Export Market(s)
Middle East, Asia

Main Domestic Market
All India

About 604.9000002 HUBA CONTROL DIFFERENTIAL PRESSURE SWITCH 0.2-3 Mbar

604.9000002 HUBA CONTROL DIFFERENTIAL PRESSURE SWITCH 0.2-3 Mbar

Model : 604.9000002

Range : 0.2....3 Mbar
Max : 50 Mbar ( -30T85 )
Max : 75 Mbar ( -30T75 )
Made In Switzerland

Product information:

The Pressure Switches of Type 604 Monitor Filters and Fans in Ventilation Ducts As Well As Air Dampers In Primary/Secondary Controls in Î”p Function The Series Divided Into Five Pressure Range Gradations Impresses With Extreme Ease Of Installation Combination Brackets,Snap-On Covers,And Screw Terminals.Unique Is The High Adjustment Accuracy Through Individual Scale Engraving

Easy To Install
User-Friendly Snap Closure For The Cover
Cable Entry Aid
Cable Strain Relief Integrated Into PG11
Combination Bracket For Vertical Or Horizontal Mounting
High Adjustment Accuracy Through Individual Scale Engraving Per Switch
Long-Term Stable Switching Points Through Trapezoidal Bead Membrane
Multilayer Contact With Gold Plating

Product Feature:

Technical Data:

Pressure Measuring Range:0...50 Mbar Relative & Difference
Sensor Weight:143g With Type C combination bracket

Field Of Application:

Media:Air Neutral Gas
Medium Temperature:-30...85Â°C
Permissible Overload On One Side:75 Mbar-30...75ÂºC 50 Mbar-30...85ÂºC

Ambient Condition:

Ambient Temperature:-30... 85Â°C
Storage Temperature:-40...85Â°C

Material:

Housing With Media Contact:PC 10% GF
Measuring Element With Media Contact:Silicone LSR Tempered At 200Â°C,Outgassing-Free
Cover With Media Contact:PC

Electrical Data:

Switching Load:5 A at 250 VAC
Resistive Switching Load:4 A at 30 VDC
Inductive Switching Load:0.8 A at 250 VAC 0.7 A at 30 VDC
Switching Load GAR Application:1 A at 250 VAC 0.2 A at 30 VDC
Contact System:Changeover Switch
Lifespan:>10000000 Schaltspiele Mechanical

Installation Guide:Installation Orientationany:Any Recommendation Vertical Pressure Connections Downwards Factory Adjustment Any Recommendation Horizontal Cover Down Switching Points Are Approx 11 Pa Lower Than The Set Scale Value Any Recommendation Horizontal Cover Upward Switching Points Are Approx 11 Pa Higher Than The Set Scale ValueApproval:

UL:MFHX2/8 Or XAAK2/8

DVGW:According to DIN EN 1854

Low Voltage Directive:2014/35/EU

Gas Appliances Directive:2016/426/EU

Applications:
AHU

CRAC

MOBILE HYDRAULIC

Accessories:Connection Set Straight:For Ventilation Duct Including 2 M Hose Plastic

Angle Type B

Combination Bracket Type C

Snap Ring:For Angle A,B,C Or Direct Mounting For Wall Thickness 1.8...2.1 MM

Snap Ring:For Angle A,B,C Or Direct Mounting For Wall Thickness 0.8...1.1 MM

Angle Type A

Fastening Screw:For Wall Thickness 1-2 MM Screw Length 6 MM Min 2 Screws Required

Connection Set 90Â° Angled:For Ventilation Duct Including 2 M Hose Metal

Calibration Certificate

Mounting Ring

Closed Fastening Ring
