Series G2000 GEMTECH Differential Pressure Gauges FOR SALE

About Series G2000 GEMTECH Differential Pressure Gauges FOR SALE

Series G2000 GEMTECH Differential Pressure Gauges  FOR SALE

Series G2000 GEMTECH Differential Pressure Gauges are Widely Utilized For Measuring Pressure of Fan And Blowing Machine,resistance of Filter,Wind Speed,Furnace Pressure,Differential Pressure Of Pore Plate,The Pressure of drum water level,Liquid Amplifier And Hydraulic Pressure System.Meantime,They Are Used To Control The Automatic Valve And Specific Value Of Air-Producer Gas In Combustion And They Are Used To Test Blood Pressure And Respiratory Pressure In Medical Health Care Equipment. There Are More Than 81 Models To Suit Your Needs Precisely.The Key Components Adopt Import Materials.
SPECIFICATION

• Ambient Temperature - -21~140-6~60

• Rated Pressure -20 inHg~30 inHg (-68~103KPa)

• Overpressure - Protective rubber stopper will be blown out if rated pressure is up to about 50.8 inHg (172KPa)

• Process Connections - 1/8" female NPT duplicate high and low pressure taps - one pair side and one pair back

• Housing - Die cast aluminum case and bezel,with acrylic cover, Exterior finish is coated gray to withstand 168 Hour Salt Spray Corrosion Test

• Accuracy - A2% of full span at 70 (21 (A3% on-0,and A4% on -00)

• Range -20 inHg~38 inHg (-68KPa~130KPa)(Special Specification also can be ordered.
  FEATURES


• OEM/ODM
• There Is No Need To Fill Liquid To Gauge.
• The Gauge Can Measure Positive Pressure,Negative Pressure And Differential Pressure.
• It Will Be Easy To Install And Measure In Different Ways Because Of Two Groups Of Ports Which Can Measure Positive And Negative Pressure.
• To Eliminate The Friction From The Movement Of Gear Wheel By The Mechanism Of Magnetic Magnet Feed.
• Exact And Stable Fixed Position Of Needle.
• The Gauge Has Great Antiknock Characteristics.
• There Are 81 Types Of Ranges.Minimum is 0-60 Pa And Maximum is 0-21-KPa
  PRODUCT APPLICATIONS


• Filter Monitoring
• Air Velocity With Pitot Tube
• Blower Vacuum Monitoring
• Fan Pressure Indication
• Duct,Room or Building Pressures
• Clean Room Positive Pressure Indication
  MODELS & ORDERING


GEMTECH By  Model Number Popularity

• FILTER BY
• Range - MM Of Water

Model	Description
G2000-100MM	DPG,Range 0-100 MM W.C., Minor Divisions 2.0.
G2000-10MM	DPG,Range 0-10 MM W.C.,Minor Divisions .20,Calibrated For Vertical Scale Position.
G2000-150MM	DPG,Range 0-150 MM W.C.
G2000-15MM	DPG,Range 0-15 MM W.C.
G2000-200MM	DPG,Range 0-200 MM W.C.
G2000-250MM	DPG,Range 0-250 MM W.C.
G2000-25MM	DPG,Range 0-25 MM W.C. Minor Divisions .50.
G2000-300MM	DPG,Range 0-300 MM W.C.
G2000-50MM	DPG,Range 0-50 MM W.C.,Minor Divisions 1.0.
G2000-6MM	DPG,Range 0-6 MM W.C.,Minor Divisions .20, Calibrated For Vertical Scale Position.
G2000-80MM	DPG,Range 0-80 MM W.C.,Minor Divisions 2.0.

Exceptional Accuracy for Critical Measurements

Achieve consistent and dependable readings with an accuracy rate of 2% of the full span at 21C (3% on -0, 4% on -00). The G2000 is expertly designed for demanding environments, providing trusted performance for your pressure monitoring needs in steam, oil, or gas processes.


Versatile Application Across Industries

Designed for flexibility, this gauge serves a broad spectrum of sectors including hotels, hospitals, malls, power plants, cement, steel, fertilizer, textiles, pharmaceuticals, food & beverage, and pulp & paper industries. Its sturdy build and precise functionality make it a reliable instrument in both industrial and commercial settings.


Durable Construction and User-Friendly Design

Outfitted with a stainless steel body, aluminum pointer, and plastic dial, the G2000 is built for resilience and reliability. The 4-inch display with analog readout ensures ease of use, while multiple thread and mounting options facilitate straightforward installation and integration into existing systems.
