Huba I Pressure Transmitter Model 520.955S032401W RANGE: 0-700 BAR OUTPUT 4-20mA

Price 10800 INR/ Piece

Get a Price/Quote

MOQ : 5 Pieces

Huba I Pressure Transmitter Model 520.955S032401W RANGE: 0-700 BAR OUTPUT 4-20mA Specification

Thread
G 1/4

Material
Stainless Steel

Usage
Liquids, Gases And Refrigerants (Including Ammonia)

Size
RANGE 0-700 BAR

Processing Type
Standard

Product Type
Huba I Pressure Transmitter Model 520.955S032401W RANGE: 0-700 BAR OUTPUT 4-20mA

Weight
150 Grams (g)

Mount Type
Panel

Color
Siliver

Scale Range
RANGE 0-700 BAR

Accuracy
0.3 %

Huba I Pressure Transmitter Model 520.955S032401W RANGE: 0-700 BAR OUTPUT 4-20mA Trade Information

Minimum Order Quantity
5 Pieces

FOB Port
New Delhi

Payment Terms
Cash Against Delivery (CAD), Cash in Advance (CID), Paypal, Cash on Delivery (COD), Cash Advance (CA)

Supply Ability
1 Piece Per Day

Delivery Time
1 Days

Main Export Market(s)
Middle East, Asia

Main Domestic Market
All India

About Huba I Pressure Transmitter Model 520.955S032401W RANGE: 0-700 BAR OUTPUT 4-20mA

www.envirotechindustrialproductsindia.in

Huba I Pressure Transmitter Model 520.955S032401W RANGE: 0-700 BAR OUTPUT 4-20mA

Relative Pressure Transmitter
Type a 520
Manufacturer a HUBA CONTROL
Model a 520.955S032401W
RANGE a 0-700 BAR
WhatsApp No.9871014210,WhatsApp No.9811065204,WhatsApp No.8376899729,WhatsApp No.8368888047,WhatsApp No.9268631221,

The Compact Type 520 Pressure Transmitter Is Based Upon The Huba Control Developed Thick Film Technology Where The Pressure Measuring Cell Is Fully Welded.This Transmitter Meets The High Burst Protection Demands And Is Suitable For The Use In All Types Of Refrigerants Including Ammonia.
Pressure Range

-1 a 9 bar / 0 a 2.5 a 1000 bar
Compact,Rugged Construction
Welded Without Sealing parts,No Elastomer Seals
Large Selection Of Connections Available.
Saving Time By Quick Cable Mounting By The Customer With Swift Connector
General Features:
Compact, Rugged Construction
Large Selection Of Connections Available
Welded Without Sealing Parts, No Elastomer Seals
Medium: Liquids, Gases And Refrigerants (Including Ammonia)
Saving Time By Quick Cable Mounting By The Customer With Swift Connector

SERIES	Type 520
PRESSURE RANGE	0 a 700 BAR
POWER SUPPLY	7 a 33 VDC
OUTPUT DC	4 a 20 mA
ELECTRICAL CONNECTION	M12x1
DESCRIPTION	Pressure Transmitter
PRESSURE CONNECTION	G 1/4
INDEX PROTECTION IP	IP67
ACCURACY	A 0.3 % fs
MEDIUM TEMPERATURE RANGE	-15 a +125 AC
RESPONSE TIME	< 2 ms, (1 ms typical)
MATERIAL	Connection Stainless Steel 1.4404 / AISI 316L
DIMENSIONS (MM)	24 x 46.7 MM
CONFORMITY	EN 61326-2-3 / IEC 68-2-27 / IEC 68-2-29 / IEC 68-2-6 / UL E325110

Versatile Pressure Monitoring

Capable of measuring pressures up to 700 BAR, the Huba I Pressure Transmitter Model 520 is suitable for a wide range of applications. Its robust stainless steel build ensures compatibility with diverse substances such as liquids, gases, and various refrigerants, including ammonia. The transmitter's adaptability makes it ideal for sectors like chemical processing, HVAC, and energy generation.

Reliable Industrial Performance

With a 4-20mA output signal, the Model 520 offers seamless integration into existing industrial control systems. Its high accuracy and efficient signal transmission support precise monitoring and control of pressure for safer and more efficient operations. The device withstands demanding conditions while maintaining consistent measurement reliability.

Easy Installation and Maintenance

Designed for panel mounting, the Huba I Pressure Transmitter comes with a G 1/4 thread, ensuring quick and secure installation. Its compact size and lightweight design (150 grams) allow flexible placement, while the polished, galvanized, and matte finishes offer extra protection and simplified cleaning and maintenance.

FAQ's of Huba I Pressure Transmitter Model 520.955S032401W RANGE: 0-700 BAR OUTPUT 4-20mA:

Q: How does the Huba I Pressure Transmitter Model 520.955S032401W operate?

A: The transmitter functions by converting the applied pressure (0-700 BAR) from liquids, gases, or refrigerants into a standardized 4-20mA electrical output signal, which can then be monitored remotely using industrial control systems.

Q: What substances can the Huba I Pressure Transmitter measure?

A: This model is suitable for measuring the pressure of various substances, including liquids, gases, steam, oil, and refrigerants such as ammonia, making it highly versatile for industrial processes.

Q: When should I use this pressure transmitter in my application?

A: You should use this transmitter when you require precise pressure measurement in systems where reliability and compatibility with aggressive or challenging media such as steam, oil, or ammonia are critical.

Q: Where can the Huba I Pressure Transmitter be installed?

A: It is designed for panel mounting and fits any setup requiring a G 1/4 threaded connection, allowing it to be used across different industrial locations and systems within India and globally.

Q: What is the benefit of the 4-20mA output provided by the device?

A: The 4-20mA output is industry-standard for transmitting analog signals with minimal interference, enabling accurate remote monitoring and seamless integration into a wide range of control and automation systems.

Q: How accurate is the Huba I Pressure Transmitter Model 520.955S032401W?

A: It offers an accuracy of 0.3%, ensuring reliable and consistent pressure measurements for critical industrial processes.

Q: What maintenance is required for this pressure transmitter?

A: Thanks to its stainless steel construction and durable finishes, the transmitter requires minimal maintenance. Routine checks for proper installation and occasional cleaning are generally sufficient to maintain optimal performance.
