Huba I Pressure Transmitter Model: 520.942S032401 RANGE: 0-160 BAR

Send Inquiry

Request To Call Back

Huba I Pressure Transmitter Model: 520.942S032401 RANGE: 0-160 BAR

Name: Huba I Pressure Transmitter Model: 520.942S032401 RANGE: 0-160 BAR
Brand: D. P. ENGINEERS
Price: 10800 INR
Availability: InStock

Price 10800 INR/ Piece

Get a Price/Quote

MOQ : 5 Pieces

Huba I Pressure Transmitter Model: 520.942S032401 RANGE: 0-160 BAR Specification

Thread
G 1/4

Material
Stainless Steel

Usage
Liquids, Gases And Refrigerants (Including Ammonia)

Size
RANGE 0-160 BAR

Processing Type
Standard

Product Type
Huba I Pressure Transmitter Model: 520.942S032401 RANGE: 0-160 BAR

Weight
150 Grams (g)

Color
Siliver

Mount Type
Panel

Scale Range
RANGE 0-160 BAR

Accuracy
0.3 %

Huba I Pressure Transmitter Model: 520.942S032401 RANGE: 0-160 BAR Trade Information

Minimum Order Quantity
5 Pieces

FOB Port
New Delhi

Payment Terms
Cash on Delivery (COD), Cash Advance (CA), Cash Against Delivery (CAD), Paypal, Cash in Advance (CID)

Supply Ability
1 Piece Per Day

Delivery Time
1 Days

Main Export Market(s)
Asia, Middle East

Main Domestic Market
All India

About Huba I Pressure Transmitter Model: 520.942S032401 RANGE: 0-160 BAR

Huba I Pressure Transmitter Model: 520.942S032401 RANGE: 0-160 BAR

Relative Pressure Transmitter
Type a 520
Manufacturer a HUBA CONTROL
Model a 520.942S032401
RANGE a 0-160 BAR

The Compact Type 520 Pressure Transmitter Is Based Upon The Huba Control Developed Thick Film Technology Where The Pressure Measuring Cell Is Fully Welded.

This Transmitter Meets The High Burst Protection Demands And Is Suitable For The Use In All Types Of Refrigerants Including Ammonia.
Pressure Range

-1 a 9 bar / 0 a 2.5 a 1000 bar
Compact,Rugged Construction
Welded Without Sealing parts,No Elastomer Seals
Large Selection Of Connections Available.
Saving Time By Quick Cable Mounting By The Customer With Swift Connector

General Features:

Compact, Rugged Construction
Large Selection Of Connections Available
Welded Without Sealing Parts, No Elastomer Seals
Medium: Liquids, Gases And Refrigerants (Including Ammonia)
Saving Time By Quick Cable Mounting By The Customer With Swift Connector

SERIES	Type 520
PRESSURE RANGE	0 a 160 BAR
POWER SUPPLY	7 a 33 VDC
OUTPUT DC	4 a 20 mA
ELECTRICAL CONNECTION	M12x1
DESCRIPTION	Pressure Transmitter
PRESSURE CONNECTION	G 1/4
INDEX PROTECTION IP	IP67
ACCURACY	A 0.3 % fs
MEDIUM TEMPERATURE RANGE	-15 a +125 AC
RESPONSE TIME	< 2 ms, (1 ms typical)
MATERIAL	Connection Stainless Steel 1.4404 / AISI 316L
DIMENSIONS (MM)	24 x 46.7 MM
CONFORMITY	EN 61326-2-3 / IEC 68-2-27 / IEC 68-2-29 / IEC 68-2-6 / UL E325110

WhatsApp No.9871014210,

WhatsApp No.9811065204,

WhatsApp No.8376899729,

WhatsApp No.8368888047,

WhatsApp No.9268631221,

Reliable Pressure Measurement

This pressure transmitter offers a wide measuring range from 0 to 160 BAR, making it suitable for diverse operational needs. The device ensures accurate readings in complex environments where fluids or gases are monitored, including steam and ammonia-based systems. Its sturdy design and consistent accuracy enhance system reliability.

Superior Stainless Steel Construction

Crafted from high-grade stainless steel, the Huba I Model 520.942S032401 provides corrosion resistance and durability, even when exposed to aggressive substances. The refined antique, polished, and galvanized finishes offer both aesthetic appeal and added protection, making it an excellent fit for industrial and commercial facilities.

Versatile Industrial Applications

Engineered for versatility, the pressure transmitter can be seamlessly integrated into systems handling steam, oil, gas, liquids, or refrigerants. Its universal G 1/4 thread and convenient panel mount design facilitate easy installation and adaptability, optimizing performance in a variety of process industries from refrigeration to petrochemical plants.

FAQ's of Huba I Pressure Transmitter Model: 520.942S032401 RANGE: 0-160 BAR:

Q: How is the Huba I Pressure Transmitter Model 520.942S032401 typically installed?

A: The transmitter features a standard G 1/4 thread and is designed for panel mounting, allowing for straightforward integration into new or existing systems. Its compact size and lightweight design make installation quick and hassle-free.

Q: What types of media can this transmitter safely measure pressure for?

A: It is suitable for measuring pressure in liquids, gases, refrigerants (including ammonia), steam, oil, and gas, making it ideal for a wide range of industrial processes.

Q: When should I choose this pressure transmitter for my application?

A: This model is best selected when high accuracy (0.3%) and durability in challenging environments are essential. It is particularly appropriate for demanding industrial operations requiring reliable measurement across a 0-160 BAR range.

Q: Where is the Huba I Pressure Transmitter Model 520.942S032401 manufactured and supplied from?

A: The transmitter is manufactured, exported, and supplied by companies based in India, catering to both domestic and international industrial sectors.

Q: What are the key steps in using or integrating this pressure transmitter into a process system?

A: Begin by securely mounting the transmitter using the panel mount and G 1/4 threading, connect to the compatible process media, and calibrate as per process requirements. Regular maintenance checks help ensure optimal and continued performance.

Q: What benefits does using a stainless steel pressure transmitter provide?

A: Stainless steel construction ensures robust resistance to corrosion, reliable operation in harsh environments, and a long service life, reducing maintenance needs and operational downtime.

Q: How does this pressure transmitter contribute to process safety and efficiency?

A: By delivering highly accurate and stable pressure measurements, it helps operators maintain safe working conditions, optimize equipment performance, and quickly respond to system anomalies.
