Huba I Pressure Transmitter Model 520.932S032401W RANGE 0-20 BAR OUTPUT 4-20mA | WhatsApp No.9268631221

Get a Price/Quote

MOQ : 5 Pieces

Huba I Pressure Transmitter Model 520.932S032401W RANGE 0-20 BAR OUTPUT 4-20mA | WhatsApp No.9268631221 Specification

Outer Size
RANGE 0-20 BAR

Thread
G 1/4

Usage
Liquids, Gases And Refrigerants (Including Ammonia)

Material
Stainless Steel

Size
RANGE 0-20 BAR

Processing Type
Standard

Product Type
Huba I Pressure Transmitter Model 520.932S032401W RANGE 0-20 BAR OUTPUT 4-20mA | WhatsApp No.9268631221

Weight
150 Grams (g)

Color
Siliver

Mount Type
Panel

Scale Range
RANGE 0-20 BAR

Accuracy
0.3 %

Huba I Pressure Transmitter Model 520.932S032401W RANGE 0-20 BAR OUTPUT 4-20mA | WhatsApp No.9268631221 Trade Information

Minimum Order Quantity
5 Pieces

FOB Port
New Delhi

Payment Terms
Cash Against Delivery (CAD), Cash in Advance (CID), Paypal, Cash on Delivery (COD), Cash Advance (CA)

Supply Ability
1 Piece Per Day

Delivery Time
1 Days

Main Export Market(s)
Asia, Middle East

Main Domestic Market
All India

About Huba I Pressure Transmitter Model 520.932S032401W RANGE 0-20 BAR OUTPUT 4-20mA | WhatsApp No.9268631221

Huba I Pressure Transmitter Model 520.932S032401W RANGE 0-20 BAR OUTPUT 4-20mA | WhatsApp No.9268631221

Relative Pressure Transmitter
Type a 520
Manufacturer a HUBA CONTROL
Model a 520.932S032401W
RANGE a 0-20 BAR
OUTPUT a 4-20mA

The Compact Type 520 Pressure Transmitter Is Based Upon The Huba Control Developed Thick Film Technology Where The Pressure Measuring Cell Is Fully Welded.

This Transmitter Meets The High Burst Protection Demands And Is Suitable For The Use In All Types Of Refrigerants Including Ammonia.

Pressure Range

-1 a 9 bar / 0 a 2.5 a 1000 bar
Compact,Rugged Construction
Welded Without Sealing parts,No Elastomer Seals
Large Selection Of Connections Available.
Saving Time By Quick Cable Mounting By The Customer With Swift Connector

General Features:

Compact, Rugged Construction
Large Selection Of Connections Available
Welded Without Sealing Parts, No Elastomer Seals
Medium: Liquids, Gases And Refrigerants (Including Ammonia)
Saving Time By Quick Cable Mounting By The Customer With Swift Connector
WhatsApp No.9871014210,
WhatsApp No.9811065204,
WhatsApp No.8376899729,
WhatsApp No.8368888047,
WhatsApp No.9268631221,

SERIES	Type 520
PRESSURE RANGE	0 a 20 BAR
POWER SUPPLY	7 a 33 VDC
OUTPUT DC	4 a 20 mA
ELECTRICAL CONNECTION	M12x1
DESCRIPTION	Pressure Transmitter
PRESSURE CONNECTION	G 1/4
INDEX PROTECTION IP	IP67
ACCURACY	A 0.3 % fs
MEDIUM TEMPERATURE RANGE	-15 a +125 AC
RESPONSE TIME	< 2 ms, (1 ms typical)
MATERIAL	Connection Stainless Steel 1.4404 / AISI 316L
DIMENSIONS (MM)	24 x 46.7 MM
CONFORMITY	EN 61326-2-3 / IEC 68-2-27 / IEC 68-2-29 / IEC 68-2-6 / UL E325110

Precise and Reliable Pressure Monitoring

This pressure transmitter offers impressive accuracy (0.3%) within a 0-20 bar range, making it ideal for sensitive applications in both industrial and commercial settings. Its 4-20mA output simplifies integration into automated control systems, ensuring reliable data transmission and improved system performance.

Built for Versatility and Durability

Engineered from stainless steel, the Model 520.932S032401W withstands exposure to challenging media such as steam, oil, gas, and even refrigerants like ammonia. The variety of high-quality finishing options further protects the transmitter in demanding operational environments.

Easy Installation and Flexible Usage

The G 1/4 threaded connection and compact construction (150g) allow for straightforward panel mounting. Designed to fit a range of process conditions, this transmitter adapts seamlessly to both new installations and upgrades of existing systems.

FAQ's of Huba I Pressure Transmitter Model 520.932S032401W RANGE 0-20 BAR OUTPUT 4-20mA | WhatsApp No.9268631221:

Q: How does the Huba I Pressure Transmitter Model 520.932S032401W ensure accurate pressure measurement?

A: This transmitter maintains high accuracy with a 0.3% tolerance within its 0-20 bar pressure range, using a reliable 4-20mA output that is widely supported by control systems. Its stainless steel build further protects the sensor from harsh media, ensuring sustained precision.

Q: What types of media can this pressure transmitter measure?

A: The Model 520.932S032401W is suitable for liquids, gases, and refrigerants-including ammonia. It is commonly used for measuring pressure in steam, oil, gas, and other industrial fluids.

Q: Where can I install this transmitter and what is its mounting type?

A: You can panel-mount this transmitter using its G 1/4 threaded connection, making it easy to integrate into a variety of industrial and commercial systems.

Q: What is the main benefit of the 4-20mA output signal?

A: The 4-20mA output is a standardized, widely-used signal in industrial automation, allowing for efficient data transmission over long distances and easy integration with PLCs and monitoring systems.

Q: When should I use this pressure transmitter?

A: This device is ideal whenever you require precise and reliable pressure monitoring in processes involving liquids, steam, oil, gas, or refrigerants within a 0-20 bar range.

Q: What finishing options are available for this model?

A: The transmitter is available in several durable finishes, including antique, polished, galvanized, and matte. These options enable you to select the best fit for specific environmental requirements.
