GEMTECH G2000-2.5KPA Differential Pressure Gauges Range 0-2.5 KPA

About GEMTECH G2000-2.5KPA Differential Pressure Gauges Range 0-2.5 KPA

GEMTECH G2000-2.5KPA Differential Pressure Gauges Range 0-2.5 KPA
Series G2000 GEMTECH Differential Pressure Gauges are Widely Utilized For Measuring Pressure of Fan And Blowing Machine,resistance of Filter,Wind Speed,Furnace Pressure,Differential Pressure Of Pore Plate,The Pressure of drum water level, Liquid Amplifier And Hydraulic Pressure System.Meantime,They Are Used To Control The Automatic Valve And Specific Value Of Air-Producer Gas In Combustion And They Are Used To Test Blood Pressure And Respiratory Pressure In Medical Health Care Equipment. There Are More Than 81 Models To Suit Your Needs Precisely.The Key Components Adopt Import Materials,
SPECIFICATION

• Ambient Temperature -   -21 140 -6 60

• Rated Pressure -20 inHg30 inHg (-68103KPa)

• Overpressure - Protective rubber stopper will be blown out if rated pressure is up to about 50.8 inHg (172KPa)

• Process Connections - 1/8" female NPT duplicate high and low pressure taps - one pair side and one pair back

• Housing - Die cast aluminum case and bezel, with acrylic cover, Exterior finish is coated gray to withstand 168 Hour Salt Spray Corrosion Test

• Accuracy - 2% of full span at 70 (21 (3% on -0,and 4% on -00)

• Range -20 inHg38 inHg (-68KPa130KPa)(Special Specification also can be ordered)

FEATURES

• OEM/ODM
• There Is No Need To Fill Liquid To Gauge
• The Gauge Can Measure Positive Pressure,Negative Pressure And Differential Pressure.
• It Will Be Easy To Install And Measure In Different Ways Because Of Two Groups Of Ports Which Can Measure Positive And Negative Pressure
• To Eliminate The Friction From The Movement Of Gear Wheel By The Mechanism Of Magnetic Magnet Feed
• Exact And Stable Fixed Position Of Needle.
• The Gauge Has Great Antiknock Characteristics
• There Are 81 Types Of Ranges.Minimum is 0-60 Pa And Maximum is 0-21-KPa

PRODUCT APPLICATIONS

• Filter Monitoring
• Air Velocity With Pitot Tube
• Blower Vacuum Monitoring
• Fan Pressure Indication
• Duct,Room or Building Pressures
• Clean Room Positive Pressure Indication

MODELS & ORDERING

GEMTECH By  Model Number Popularity

• FILTER BY
• Range - Kilopascals

Sort by  Model Number Popularity

Model	Description
G2000-1.5KPA	DPG,Range 0-1.5 kPa,Minor Divisions .05.
G2000-10KPA	DPG,Range 0-10 kPa,Minor Divisions .20.
G2000-15KPA	DPG,Range 0-15 kPa,Minor Divisions .50.
G2000-1KPA	DPG,Range 0-1 kPa,Minor Divisions .02.
G2000-20KPA	DPG,Range 0-20 kPa,Minor Divisions .50.
G2000-25KPA	DPG,Range 0-25 kPa,Minor Divisions .50.
G2000-2KPA	DPG,Range 0-2 kPa,Minor Divisions .05.
G2000-30KPA	DPG,Range 0-30 kPa,Minor Divisions 1.0.
G2000-3KPA	DPG, Range 0-3 kPa,Minor Divisions.10.
G2000-4KPA	DPG,Range 0-4 kPa,Minor Divisions.10.
G2000-5KPA	DPG,Range 0-5 kPa,Minor Divisions.10.
G2000-8KPA	DPG,Range 0-8 kPa,Minor Divisions.20.

Versatile Pressure Measurement Solutions

GEMTECH G2000-2.5KPA Differential Pressure Gauges are engineered for accurate monitoring of pressure across applications in pharmaceuticals, hospitality, power plants, cement, steel, and textile industries. Back-mounted and available in several finishes, the gauge adapts seamlessly for operational needs, offering resilience and reliability even under rigorous conditions. Its analog display, aluminum pointer, and precise scale make pressure readings straightforward.


Durability Meets Design Excellence

Built with a stainless steel body and plastic dial, the GEMTECH gauge balances robust performance with visual appeal. Finish options such as Antique, Polished, Galvanized, and Matte support design integration within different environments. The device is lightweight at just 550 grams and available in a standardized 4-inch (100 mm) size, allowing easy installation and long-lasting operation.
