Series G2000 GEMTECH Differential Pressure Gauges Model G2300-500 Pa

About Series G2000 GEMTECH Differential Pressure Gauges Model G2300-500 Pa

Series G2000 GEMTECH Differential Pressure Gauges Model G2300-500 Pa
Series G2000 GEMTECH Differential Pressure Gauges are Widely Utilized For Measuring Pressure of Fan And Blowing Machine, resistance of Filter, Wind Speed, Furnace Pressure,Differential Pressure Of Pore Plate,The Pressure of drum water level,Liquid Amplifier And Hydraulic Pressure System.Meantime,They Are Used To Control The Automatic Valve And Specific Value Of Air-Producer Gas In Combustion And They Are Used To Test Blood Pressure And Respiratory Pressure In Medical Health Care Equipment.There Are More Than 81 Models To Suit Your Needs Precisely.The Key Components Adopt Import Materials.
SPECIFICATION

• Ambient Temperature -   -21 ~140 -6 ~60
• Rated Pressure -20 inHg~30 inHg (-68~103KPa)
• Overpressure - Protective rubber stopper will be blown out if rated pressure is up to about 50.8 inHg (172KPa)
• Process Connections - 1/8" female NPT duplicate high and low pressure taps - one pair side and one pair back
• Housing - Die cast aluminum case and bezel,With acrylic cover,Exterior finish is coated gray to withstand 168 Hour Salt Spray Corrosion Test
• Accuracy - A2% of full span at 70(21(A3% on -0, and A4% on -00)
• Range -20 inHg~38 inHg (-68KPa~130KPa)(Special Specification also can be ordered.

FEATURES

• OEM/ODM
• There Is No Need To Fill Liquid To Gauge.
• The Gauge Can Measure Positive Pressure,Negative Pressure And Differential Pressure.
• It Will Be Easy To Install And Measure In Different Ways Because Of Two Groups Of Ports Which Can Measure Positive And Negative Pressure.
• To Eliminate The Friction From The Movement Of Gear Wheel By The Mechanism Of Magnetic Magnet Feed.
• Exact And Stable Fixed Position Of Needle.
• The Gauge Has Great Antiknock Characteristics.
• There Are 81 Types Of Ranges.Minimum is 0-60 Pa And Maximum is 0-21-KPa

PRODUCT APPLICATIONS

• Filter Monitoring
• Air Velocity With Pitot Tube
• Blower Vacuum Monitoring
• Fan Pressure Indication
• Duct,Room or Building Pressures
• Clean Room Positive Pressure Indication

MODELS & ORDERING

GEMTECH By  Model Number Popularity

• FILTER BY
• Range - Pascals

Model	Description
G2000-30PA	DPG,Range 0-30 Pa,minor divisions 1.0, calibrated for vertical scale position
G2000-60PA	DPG,Range 0-60 Pa,minor divisions 1.0, calibrated for vertical scale position
G2000-100PA	DPG,Range 0-100 Pa,minor divisions 2.0, calibrated for vertical scale position
G2000-125PA	DPG,Range 0-125 Pa,minor divisions 5.0 calibrated for vertical scale position
G2000-250PA	DPG,Range 0-250 Pa,minor divisions 5.0
G2000-300PA	DPG,Range 0-300 Pa,minor divisions 10.0
G2000-500PA	DPG,Range 0-500 Pa,minor divisions 10.0
G2000-750PA	DPG,Range 0-750 Pa,minor divisions 25.0

Versatile Industrial Applications

Engineered for multifunctional use, the GEMTECH G2300-500 Pa differential pressure gauge is ideal for settings such as hospitals, hotels, malls, power plants, cement, steel, fertilizer, and textile industries. Its robust build and flexible mounting options make it dependable for continuous industrial monitoring.


Reliable and Accurate Readings

Designed to deliver consistent results, this gauge features an analog display with a clear, easy-to-read dial. The aluminum pointer and metal alloy body promote long-lasting precision. Its impressive accuracy ensures trustworthy measurements, essential across pharmaceuticals, food production, and pulp industries.
