Series G2000 GEMTECH Differential Pressure Gauges 15 PSIG

Get a Price/Quote

MOQ : 25 Pieces

Series G2000 GEMTECH Differential Pressure Gauges 15 PSIG Specification

Thread
1/8" female NPT duplicate high and low pressure taps - one pair side and one pair back

Outer Size
4 inch / 100 mm

Display
Analog

Material
Stainless Steel

Usage
pharmaceutical,Hotel,Malls,Hospital,OT,POWER PLANT,CEMENT PLANT,STEEL PLANT,FERTILIZER,TEXTILE,Pharmaceutical Manufacture,Food And Beverages Industry,Pulp And Paper Industry,Textile Industry

Dial Material
Plastic

Pointer Material
Aluminum

Size
4 inch / 100 mm

Processing Type
Standard

Product Type
Series G2000 GEMTECH Differential Pressure Gauges 15 PSIG

Diameter
4 inch / 100 Millimeter (mm)

Weight
550 Grams (g)

Color
Black

Mount Type
Back

Scale Range
MM WC/ CM / PAC / KPA / INCH

Accuracy
2% of full span at 70(21(3% on -0, and 4% on -00) %

Finishing
Antique, Polished, Galvanized, Matte

Series G2000 GEMTECH Differential Pressure Gauges 15 PSIG Trade Information

Minimum Order Quantity
25 Pieces

FOB Port
Delhi

Payment Terms
Cash Against Delivery (CAD), Cash Advance (CA), Cash on Delivery (COD), Paypal

Supply Ability
1 Piece Per Day

Delivery Time
1 Days

Main Export Market(s)
Middle East, Asia

Main Domestic Market
All India

About Series G2000 GEMTECH Differential Pressure Gauges 15 PSIG

Series G2000 GEMTECH Differential Pressure Gauges 15 PSIG
Series G2000 GEMTECH Differential Pressure Gauges are Widely Utilized For Measuring Pressure of Fan And Blowing Machine,resistance of Filter,Wind Speed, Furnace Pressure,Differential Pressure Of Pore Plate,The Pressure of drum water level,Liquid Amplifier And Hydraulic Pressure System.Meantime,They Are Used To Control The Automatic Valve And Specific Value Of Air-Producer Gas In Combustion And They Are Used To Test Blood Pressure And Respiratory Pressure In Medical Health Care Equipment.There Are More Than 81 Models To Suit Your Needs Precisely.The Key Components Adopt Import Materials.SPECIFICATION

Ambient Temperature - -21 ~140 -6 ~60

Rated Pressure -20 inHg~30 inHg (-68~103KPa)

Overpressure - Protective rubber stopper will be blown out if rated pressure is up to about 50.8 inHg (172KPa)

Process Connections - 1/8" female NPT duplicate high and low pressure taps - one pair side and one pair back

Housing - Die cast aluminum case and bezel, with acrylic cover, Exterior finish is coated gray to withstand 168 Hour Salt Spray Corrosion Test

Accuracy - A2% of full span at 70(21(A3% on -0, and A4% on -00)

Range -20 inHg~38 inHg (-68KPa~130KPa)(Special Specification also can be ordered.)

FEATURES

OEM/ODM

There Is No Need To Fill Liquid To Gauge.

The Gauge Can Measure Positive Pressure,Negative Pressure And Differential Pressure.

It Will Be Easy To Install And Measure In Different Ways Because Of Two Groups Of Ports Which Can Measure Positive And Negative Pressure.

To Eliminate The Friction From The Movement Of Gear Wheel By The Mechanism Of Magnetic Magnet Feed.

Exact And Stable Fixed Position Of Needle.

The Gauge Has Great Antiknock Characteristics.

There Are 81 Types Of Ranges.Minimum is 0-60 Pa And Maximum is 0-21-KPa

PRODUCT APPLICATIONS

Filter Monitoring

Air Velocity With Pitot Tube

Blower Vacuum Monitoring

Fan Pressure Indication

Duct,Room or Building Pressures

Clean Room Positive Pressure Indication

MODELS & ORDERING

GEMTECH By Model Number Popularity

FILTER BY

Range - MM Of Water

Model Description

G2000-100MM DPG,Range 0-100 MM W.C., Minor Divisions 2.0.

G2000-10MM DPG,Range 0-10 MM W.C.,Minor Divisions .20,Calibrated For Vertical Scale Position.

G2000-150MM DPG,Range 0-150 MM W.C.

G2000-15MM DPG,Range 0-15 MM W.C.

G2000-200MM DPG,Range 0-200 MM W.C.

G2000-250MM DPG,Range 0-250 MM W.C.

G2000-25MM DPG,Range 0-25 MM W.C. Minor Divisions .50.

G2000-300MM DPG,Range 0-300 MM W.C.

G2000-50MM DPG,Range 0-50 MM W.C., Minor Divisions 1.0.

G2000-6MM DPG,Range 0-6 MM W.C., Minor Divisions .20, Calibrated For Vertical Scale Position.

G2000-80MM DPG,Range 0-80 MM W.C., Minor Divisions 2.0.

Versatile Pressure Measurement for Multiple Industries

The G2000 GEMTECH Gauge provides accurate pressure differential readings for steam, oil, gas, and water. Its stainless steel construction ensures durability, while the 4-inch dial and multiple tap options make it suitable for demanding settings in pharmaceuticals, power plants, hospitals, hotels, and manufacturing industries.

Robust Construction and Reliable Accuracy

Designed with a high-quality stainless steel body and precise aluminum pointer, the G2000 offers 2% accuracy at standard conditions. Its antique, polished, galvanized, and matte finishes enhance both resiliency and visual appeal. The 1/8" NPT threading supports flexible installation across systems.

FAQ's of Series G2000 GEMTECH Differential Pressure Gauges 15 PSIG:

Q: How does the Series G2000 GEMTECH Differential Pressure Gauge operate?
A: This gauge works by measuring the difference between two pressure points using its dual high and low pressure taps. It provides analog readings on a 4-inch dial, ensuring straightforward monitoring of pressure changes in fluids such as steam, oil, gas, and water.

Q: What industries benefit from using this differential pressure gauge?
A: The G2000 gauge is widely used in pharmaceuticals, hospitals, hotels, power plants, cement plants, steel plants, fertilizer production, textile manufacturing, food and beverage processing, and the pulp and paper industry. Its robust design supports both critical and routine pressure monitoring tasks.

Q: Where can the Series G2000 gauge be installed within a system?
A: Thanks to its multiple 1/8" female NPT pressure taps located both on the side and back, the gauge allows for flexible mounting options. It can be installed in new or existing pipelines and equipment that require accurate pressure differential monitoring.

Q: What accuracy can users expect from this pressure gauge?
A: At 70F (21C), the Series G2000 delivers an accuracy of 2% of full span, ensuring dependable readings for process control. Different conditions might slightly alter this accuracy, but it consistently stays within industrial standards.

Q: When should this gauge be used during a process?
A: It is ideal for continuous monitoring of pressure differentials to ensure safe, efficient equipment operation. Use it during system start-up, routine maintenance, or whenever precise pressure checks are needed to maintain process integrity.

Q: What is the benefit of having dual pressure taps on this gauge?
A: Dual high and low taps (on side and back) enable greater installation flexibility and make the gauge suitable for different configuration requirements, improving ease of access and maintenance without disrupting process flow.

Q: How does the construction of the Series G2000 enhance its longevity?
A: With a stainless steel body, plastic dial, and finishes like antique, polished, or galvanized, the gauge resists corrosion and wear, making it reliable for long-term usage in both standard and demanding industrial environments.

Model	Description
G2000-100MM	DPG,Range 0-100 MM W.C., Minor Divisions 2.0.
G2000-10MM	DPG,Range 0-10 MM W.C.,Minor Divisions .20,Calibrated For Vertical Scale Position.
G2000-150MM	DPG,Range 0-150 MM W.C.
G2000-15MM	DPG,Range 0-15 MM W.C.
G2000-200MM	DPG,Range 0-200 MM W.C.
G2000-250MM	DPG,Range 0-250 MM W.C.
G2000-25MM	DPG,Range 0-25 MM W.C. Minor Divisions .50.
G2000-300MM	DPG,Range 0-300 MM W.C.
G2000-50MM	DPG,Range 0-50 MM W.C., Minor Divisions 1.0.
G2000-6MM	DPG,Range 0-6 MM W.C., Minor Divisions .20, Calibrated For Vertical Scale Position.
G2000-80MM	DPG,Range 0-80 MM W.C., Minor Divisions 2.0.
