Series G2000 GEMTECH Differential Pressure Gauge By SIDCUL Rudrapur Uttarakhand

Send Inquiry

Request To Call Back

Series G2000 GEMTECH Differential Pressure Gauge By SIDCUL Rudrapur Uttarakhand

Get a Price/Quote

MOQ : 1 Piece

Series G2000 GEMTECH Differential Pressure Gauge By SIDCUL Rudrapur Uttarakhand Specification

Thread
1/8"

Display
Analog

Outer Size
4 inch / 100 mm

Material
Stainless Steel

Usage
pharmaceutical,Hotel,Malls,Hospital,OT,POWER PLANT,CEMENT PLANT,STEEL PLANT,FERTILIZER,TEXTILE,Pharmaceutical Manufacture,Food And Beverages Industry,Pulp And Paper Industry,Textile Industry

Dial Material
Plastic

Size
4 inch / 100 mm

Pointer Material
Aluminum

Processing Type
Standard

Diameter
4 inch / 100 Millimeter (mm)

Product Type
Series G2000 GEMTECH Differential Pressure Gauge By SIDCUL Rudrapur Uttarakhand

Weight
550 Grams (g)

Color
Black

Mount Type
Back

Scale Range
MM WC/ CM / PAC / KPA / INCH / PSI

Accuracy
2% of full span at 70(21(3% on -0, and 4% on -00) %

Finishing
Antique, Polished, Galvanized, Matte

Series G2000 GEMTECH Differential Pressure Gauge By SIDCUL Rudrapur Uttarakhand Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Against Delivery (CAD), Cash Advance (CA), Cash in Advance (CID), Cash on Delivery (COD)

Main Export Market(s)
Asia, Middle East

Main Domestic Market
All India

About Series G2000 GEMTECH Differential Pressure Gauge By SIDCUL Rudrapur Uttarakhand

GEMTECH Series 2000 Differential Pressure Gauges wholesalers Bata hospital in Delhi

Series G2000 GEMTECH Differential Pressure Gauge By SIDCUL Rudrapur Uttarakhand

Series G2000 GEMTECH Differential Pressure Gauges are Widely Utilized For Measuring Pressure of Fan And Blowing Machine, resistance of Filter, Wind Speed, Furnace Pressure, Differential Pressure Of Pore Plate,The Pressure of drum water level, Liquid Amplifier And Hydraulic Pressure System. Meantime,They Are Used To Control The Automatic Valve And Specific Value Of Air-Producer Gas In Combustion And They Are Used To Test Blood Pressure And Respiratory Pressure In Medical Health Care Equipment. There Are More Than 81 Models To Suit Your Needs Precisely.The Key Components Adopt Import Materials.
GEMTECH Differential Pressure Gauge in Bara Hindu Rao Hospital SPECIFICATION

Ambient Temperature - -21 ~140 -6 ~60

Rated Pressure -20 inHg~30 inHg (-68~103KPa)

Overpressure - Protective rubber stopper will be blown out if rated pressure is up to about 50.8 inHg (172KPa)

Process Connections - 1/8" female NPT duplicate high and low pressure taps - one pair side and one pair back

Housing - Die cast aluminum case and bezel, with acrylic cover, Exterior finish is coated gray to withstand 168 Hour Salt Spray Corrosion Test

Accuracy - A2% of full span at 70(21(A3% on -0, and A4% on -00)

Range -20 inHg~38 inHg (-68KPa~130KPa)(Special Specification also can be ordered.)

FEATURES

OEM/ODM
There Is No Need To Fill Liquid To Gauge.
The Gauge Can Measure Positive Pressure,Negative Pressure And Differential Pressure.
It Will Be Easy To Install And Measure In Different Ways Because Of Two Groups Of Ports Which Can Measure Positive And Negative Pressure.
To Eliminate The Friction From The Movement Of Gear Wheel By The Mechanism Of Magnetic Magnet Feed.
Exact And Stable Fixed Position Of Needle.
The Gauge Has Great Antiknock Characteristics.
There Are 81 Types Of Ranges.Minimum is 0-60 Pa And Maximum is 0-21-KPa

PRODUCT APPLICATIONS

Filter Monitoring
Air Velocity With Pitot Tube
Blower Vacuum Monitoring
Fan Pressure Indication
Duct,Room or Building Pressures
Clean Room Positive Pressure Indication

MODELS & ORDERING

GEMTECH By Model Number Popularity

FILTER BY
Range - MM Of Water

Model	Description
G2000-100MM	DPG,Range 0-100 MM W.C., Minor Divisions 2.0.
G2000-10MM	DPG,Range 0-10 MM W.C.,Minor Divisions .20,Calibrated For Vertical Scale Position.
G2000-150MM	DPG,Range 0-150 MM W.C.
G2000-15MM	DPG,Range 0-15 MM W.C.
G2000-200MM	DPG,Range 0-200 MM W.C.
G2000-250MM	DPG,Range 0-250 MM W.C.
G2000-25MM	DPG,Range 0-25 MM W.C. Minor Divisions .50.
G2000-300MM	DPG,Range 0-300 MM W.C.
G2000-50MM	DPG,Range 0-50 MM W.C., Minor Divisions 1.0.
G2000-6MM	DPG,Range 0-6 MM W.C., Minor Divisions .20, Calibrated For Vertical Scale Position.
G2000-80MM	DPG,Range 0-80 MM W.C., Minor Divisions 2.0.

GEMTECH Differential Pressure Gauge in Bara Hindu Rao Hospital

Reliable Differential Pressure Measurement

The Series G2000 GEMTECH Gauge delivers precise differential pressure readings for steam, oil, and gas. Built from sturdy stainless steel and equipped with an analog display, it is well-suited for rigorous industrial applications, ensuring optimal system performance and safety at all times.

Versatile Applications Across Industries

Designed to support a broad spectrum of industries, including pharmaceuticals, power plants, hotels, malls, hospitals, textiles, and food processing, this gauge offers flexibility. Its range of scale options and corrosion-resistant finish make it ideal for demanding environments.

FAQ's of Series G2000 GEMTECH Differential Pressure Gauge By SIDCUL Rudrapur Uttarakhand:

Q: How is the Series G2000 GEMTECH Differential Pressure Gauge installed?

A: This gauge features a back mount with a 1/8-inch thread, simplifying installation onto compatible pipework or panels. Ensure the mount is secure and the orientation allows for easy viewing of the analog display.

Q: What pressure types and media are measurable with this gauge?

A: The Series G2000 GEMTECH Differential Pressure Gauge is engineered to measure pressure in steam, oil, and gas lines, making it suitable for a range of industrial processes.

Q: When should this differential pressure gauge be used?

A: Utilize this gauge whenever accurate differential pressure measurement is essential for system performance and safety, such as during monitoring or maintenance in pharmaceutical manufacturing, chemical plants, power, cement, steel, fertilizer, and food industries.

Q: Where can this gauge be applied within industrial facilities?

A: Its sturdy build and corrosion-resistant materials make it suitable for various facility environments-such as operating rooms, process lines, plant floors, or wherever differential pressure readings are needed in hospitals, hotels, malls, manufacturing plants, and more.

Q: What is the measuring accuracy of the Series G2000 GEMTECH Gauge?

A: The gauge offers a measuring accuracy of 2% of full span at 70F (21C), ensuring reliable readings for process monitoring and control.

Q: What are the benefits of using this gauge for pressure measurement?

A: Benefits include high measurement accuracy, versatility across media and scale units, robust stainless steel construction, and compatibility with a wide range of industrial applications. Its analog display and compact, back-mount design provide ease of use and clear visibility.
