Popular Cities GEMTECH Differential Pressure Gauge Wholesalers by Sonepat

Send Inquiry

Request To Call Back

Popular Cities GEMTECH Differential Pressure Gauge Wholesalers by Sonepat

Get a Price/Quote

MOQ : 50 Pieces

Popular Cities GEMTECH Differential Pressure Gauge Wholesalers by Sonepat Specification

Thread
1/8" female NPT duplicate high and low pressure taps - one pair side and one pair back

Outer Size
4 inch / 100 mm

Display
Analog

Usage
Blower Vacuum Monitoring,Fan Pressure Indication,Duct, Room Or Building Pressures Etc

Material
Stainless Steel

Dial Material
Plastic

Size
4 inch / 100 mm

Pointer Material
Aluminum

Processing Type
Standard

Diameter
4 inch / 100 Millimeter (mm)

Product Type
Popular Cities GEMTECH Differential Pressure Gauge Wholesalers by Sonepat

Weight
550 Grams (g)

Mount Type
Back

Color
Black

Scale Range
MM WC/ CM / PAC / KPA / INCH / PSI

Accuracy
2% of full span at 70(21(3% on -0, and 4% on -00) %

Popular Cities GEMTECH Differential Pressure Gauge Wholesalers by Sonepat Trade Information

Minimum Order Quantity
50 Pieces

FOB Port
Delhi

Payment Terms
Cash in Advance (CID), Cash on Delivery (COD), Paypal, Cash Against Delivery (CAD), Cash Advance (CA)

Supply Ability
1 Piece Per Day

Delivery Time
1 Days

Main Domestic Market
All India

About Popular Cities GEMTECH Differential Pressure Gauge Wholesalers by Sonepat

GEMTECH DIFFERENTIAL PRESSURE GAUGE IN Belagola Industrial Area Metagalli

Popular Cities GEMTECH Differential Pressure Gauge Wholesalers by Sonepat
Series G2000 GEMTECH Differential Pressure Gauges are Widely Utilized For Measuring Pressure of Fan And Blowing Machine,resistance of Filter, Wind Speed, Furnace Pressure,Differential Pressure Of Pore Plate,The Pressure of drum water level,Liquid Amplifier And Hydraulic Pressure System.Meantime,They Are Used To Control The Automatic Valve And Specific Value Of Air-Producer Gas In Combustion And They Are Used To Test Blood Pressure And Respiratory Pressure In Medical Health Care Equipment.There Are More Than 81 Models To Suit Your Needs Precisely.The Key Components Adopt Import Materials.
SPECIFICATION

Ambient Temperature - -21 ~140 -6 ~60

Rated Pressure -20 inHg~30 inHg (-68~103KPa)

Overpressure - Protective rubber stopper will be blown out if rated pressure is up to about 50.8 inHg (172KPa)

Process Connections - 1/8" female NPT duplicate high and low pressure taps - one pair side and one pair back

Housing - Die cast aluminum case and bezel, with acrylic cover, Exterior finish is coated gray to withstand 168 Hour Salt Spray Corrosion Test

Accuracy - A2% of full span at 70(21(A3% on -0, and A4% on -00)

Range -20 inHg~38 inHg (-68KPa~130KPa)(Special Specification also can be ordered.)

FEATURES

OEM/ODM
There Is No Need To Fill Liquid To Gauge.
The Gauge Can Measure Positive Pressure,Negative Pressure And Differential Pressure.
It Will Be Easy To Install And Measure In Different Ways Because Of Two Groups Of Ports Which Can Measure Positive And Negative Pressure.
To Eliminate The Friction From The Movement Of Gear Wheel By The Mechanism Of Magnetic Magnet Feed.
Exact And Stable Fixed Position Of Needle.
The Gauge Has Great Antiknock Characteristics.
There Are 81 Types Of Ranges.Minimum is 0-60 Pa And Maximum is 0-21-KPa

PRODUCT APPLICATIONS

Filter Monitoring
Air Velocity With Pitot Tube
Blower Vacuum Monitoring
Fan Pressure Indication
Duct,Room or Building Pressures
Clean Room Positive Pressure Indication

MODELS & ORDERING

GEMTECH By Model Number Popularity

FILTER BY
Range - MM Of Water

Model	Description
G2000-100MM	DPG,Range 0-100 MM W.C., Minor Divisions 2.0.
G2000-10MM	DPG,Range 0-10 MM W.C.,Minor Divisions .20,Calibrated For Vertical Scale Position.
G2000-150MM	DPG,Range 0-150 MM W.C.
G2000-15MM	DPG,Range 0-15 MM W.C.
G2000-200MM	DPG,Range 0-200 MM W.C.
G2000-250MM	DPG,Range 0-250 MM W.C.
G2000-25MM	DPG,Range 0-25 MM W.C. Minor Divisions .50.
G2000-300MM	DPG,Range 0-300 MM W.C.
G2000-50MM	DPG,Range 0-50 MM W.C., Minor Divisions 1.0.
G2000-6MM	DPG,Range 0-6 MM W.C., Minor Divisions .20, Calibrated For Vertical Scale Position.
G2000-80MM	DPG,Range 0-80 MM W.C., Minor Divisions 2.0.

Precision for Diverse Applications

This differential pressure gauge is tailored for professionals needing reliable monitoring of pressure differences in blowers, ducts, fans, and room environments. The stainless steel construction ensures durability, while the analog display delivers straightforward readings even in challenging conditions.

Superior Build and Versatile Mounting

With a choice of antique, polished, galvanized, or matte finishes, the gauge complements both modern and classic setups. The back mount and standard 1/8" NPT twin taps (side and back) offer industries easy installation and configuration for varied system designs.

FAQ's of Popular Cities GEMTECH Differential Pressure Gauge Wholesalers by Sonepat:

Q: How does the GEMTECH Differential Pressure Gauge operate in various environments?

A: The gauge measures pressure differences in steam, oil, or gas systems using its analog mechanism and stainless steel housing, providing accurate readings for blower, vacuum, fan, duct, and room or building pressure monitoring.

Q: What installation options are available for the GEMTECH Differential Pressure Gauge?

A: It provides back mount installation and is equipped with duplicate 1/8" female NPT high and low pressure taps on both the side and back, enabling adaptable connections for different setups.

Q: When is it recommended to use this pressure gauge?

A: Use this gauge whenever you require precise monitoring in HVAC, industrial, or building management applications where tracking differential pressure is critical for system safety and performance.

Q: Where are these GEMTECH gauges commonly used?

A: They are widely implemented in industries across India for blower vacuum systems, fan pressure indication, ductwork, building pressure measurement, and other environmental monitoring requirements.

Q: What is the process for connecting the gauge to a pressure system?

A: Connect the differential gauge using the provided 1/8" NPT taps by attaching high and low pressure lines to the designated inlets on either the side or back, ensuring a secure and correct fit for accurate measurement.

Q: How does the gauge's accuracy benefit operational reliability?

A: With an accuracy of 2% of the full span at standard conditions, the gauge delivers reliable data, helping users maintain optimal system performance and promptly detect abnormal pressure conditions.
