Magnehelic Gauge Nozzles

Name: Magnehelic Gauge Nozzles
Brand: D. P. ENGINEERS
Price: 150 INR
Availability: InStock

Price 150 INR/ Piece

Get a Price/Quote

MOQ : 25 Pieces

Magnehelic Gauge Nozzles Specification

Thread
1/8 NPT

Display
Analog

Outer Size
Standard

Seal Material
Neoprene Rubber

Grade
Industrial

Sensor Type
Nozzle Type

Material
Brass

Dial Material
Aluminum

Pointer Material
Aluminum

Processing Type
Machined

Diameter
2 (50 mm)

Glass Size
50 mm

Mount Type
Panel Mount

Scale Range
0-60 psi

Accuracy
±2% of Full Scale

Accessories
Mounting Screws, Gasket

Leak Proof Design
Yes

Impact Resistance
Moderate

Manufacturing Standard
ISI Certified

Body Color
Silver

Service Life
High Durability

Temperature Range
-20C to 60C

Corrosion Resistance
Excellent

Connection Type
Male

Compatibility
Compatible with Magnehelic Gauges Models

Easy Installation
Yes

Application
Used in Pressure Calibration, Differential Pressure Measurement

Magnehelic Gauge Nozzles Trade Information

Minimum Order Quantity
25 Pieces

FOB Port
Delhi

Payment Terms
Cash on Delivery (COD), Paypal, Cash Advance (CA), Cash Against Delivery (CAD), Cash in Advance (CID)

Supply Ability
1 Piece Per Day

Delivery Time
1 Days

Main Export Market(s)
Middle East, Asia

Main Domestic Market
All India

About Magnehelic Gauge Nozzles

Magnehelic Gauge Nozzles

We are offering Magnehelic Gauge Nozzles to our client.

Features:

Excellent air velocity monitoring efficiency
Compact design
Easy to operate and maintain

Specifications:

Application Scene: Home Gardening
Shape: Square
Size: 1/2"-3/4"

Robust Construction for Industrial Demands

Manufactured from machined brass and finished with nickel plating, these nozzles withstand harsh industrial environments, demonstrating moderate impact resistance and exceptional resistance to corrosion. The overall design prioritizes both longevity and reliability, ensuring stable performance during repeated pressure measurements and calibrations.

Precision and Easy Integration

Engineered to deliver accuracy within 2% of full scale, these nozzles are compatible with all standard Magnehelic gauge models. The analog display, neoprene rubber seals, and aluminum dial/pointer all contribute to straightforward, leak-resistant installation and simple maintenance for both exporters and users across India.

FAQs of Magnehelic Gauge Nozzles:

Q: How are Magnehelic Gauge Nozzles installed on a panel mount system?

A: Magnehelic Gauge Nozzles can be easily installed on a panel mount system using their 1/8 NPT male thread. Mounting screws and gaskets provided with the nozzle ensure a secure and leak-proof connection to compatible Magnehelic gauges.

Q: What benefits do these nozzles provide for pressure calibration applications?

A: These nozzles deliver high accuracy (2% of full scale), a leak proof design, and excellent corrosion resistance. This combination ensures precise pressure calibration, consistent measurement, and long-lasting operation, reducing maintenance needs.

Q: When should Magnehelic Gauge Nozzles be used for differential pressure measurement?

A: They are ideal for use when accurate, reliable measurement of air or non-corrosive gas pressure differences is essential, especially in calibration labs, HVAC setups, or process control environments within the -20C to 60C temperature range.

Q: Where are these nozzles typically applied in industrial settings?

A: These nozzles are typically used in industrial panels and calibration rigs, where they connect Magnehelic gauges to air or non-corrosive gas lines for monitoring and adjusting differential pressures.

Q: What makes these nozzles compatible with all Magnehelic gauge models?

A: Their standardized 1/8 NPT male thread, matched processing dimensions, and overall machined design allow seamless integration with all Magnehelic gauge models, ensuring a reliable interface and accurate readings.

Q: How does the nozzles construction contribute to its high durability and corrosion resistance?

A: The use of machined brass body with a nickel plating provides a robust shield against physical damage and corrosion. This, along with neoprene rubber seals, ensures the nozzles longevity and consistent performance in industrial environments.
