Kimo CP 300 Pressure Transmitter

Get a Price/Quote

MOQ : 25 Pieces

Kimo CP 300 Pressure Transmitter Specification

Display
Digital LCD

Grade
Industrial

Seal Material
Integrated

Outer Size
87 x 62 mm

Sensor Type
Differential Pressure

Thread
M6 or 1/8

Material
ABS Plastic

Processing Type
Microprocessor Based

Mount Type
Wall Mounted

Scale Range
0 to 1000 Pa (other ranges available)

Accuracy
0.5% of Full Scale

Measure Pressure Of
Air and Neutral Gas

Accessories
Mounting Bracket

Zero and Span adjustment
Via front panel

Protection class
IP65

Weight
Approx. 150 g

Response time
< 1 second

Temperature range
0C to +50C

Electrical connection
3-wire via cable gland

Output
0-10V and 4-20mA selectable

Power supply
24 V AC/DC

Installation
Wall or duct mount

Kimo CP 300 Pressure Transmitter Trade Information

Minimum Order Quantity
25 Pieces

FOB Port
Delhi

Payment Terms
Cash on Delivery (COD), Paypal, Cash Against Delivery (CAD), Cash Advance (CA), Cash in Advance (CID)

Supply Ability
1 Piece Per Day

Delivery Time
1 Days

Main Export Market(s)
Middle East, Asia

Main Domestic Market
All India

About Kimo CP 300 Pressure Transmitter

Kimo CP 300 Pressure Transmitter Wholsaler in Delhi

Kimo CP 300 Pressure Transmitter

Kimo CP 300 Pressure Transmitter with advanced features
Part Number: CP300
Measuring range : from 0/+10 Pa to -10 000/+10 000 Pa.
Configurable intermediary and central zero ranges.
Technical data

Air velocity and airflow functions (optional)
Interchangeable measuring sensor (SPI technology)
Simultaneous display of 1 to 4 parameters
External transmitter unputs (KIMO class 200 and 300) and thermocouple K
2 output 4-20 mA or 0-10 V (4 wires), RS 232, 2 RCR relays 6A/230 Vac
2 visual (dual color LED) and audible (buzzer) alarms
Software, keypad or remote control configuration
MODBUS network RS 485 system (optional)
ABS or ALU IP 65 housing, with or without backlit gaphic display
Mounting with the 1/4 turn system with wall-mount plate
NEW : 0.1 Pa resolution (ref. CP301)

Versatile Output and Easy Setup

The CP 300 accommodates varying system requirements by offering both 0-10V and 4-20mA output options, which are selectable during installation. Its front-panel zero and span adjustments allow users to calibrate the transmitter without hassle, ensuring accurate readings tailored to different environments.

Robust Design for Industrial Settings

Engineered with a high-grade ABS housing and rated IP65, the CP 300 is built to withstand demanding conditions typical of industrial and HVAC applications. Its wall or duct-mount versatility, compact size, and included mounting bracket streamline the installation process.

Reliable Measurement & Quick Response

Featuring a digital LCD display and microprocessor-based circuitry, the CP 300 provides clear, real-time differential pressure measurements with a response time of less than one second. This ensures rapid detection of pressure changes, contributing to process efficiency and safety.

FAQs of Kimo CP 300 Pressure Transmitter:

Q: How can I adjust the zero and span settings on the Kimo CP 300 Pressure Transmitter?

A: The zero and span of the CP 300 can be easily adjusted using the controls located on the front panel, enabling accurate calibration directly on site without specialized equipment.

Q: What types of gases can the CP 300 Pressure Transmitter measure?

A: The transmitter is specifically designed to measure differential pressure of air and neutral (non-corrosive) gases, making it suitable for ventilation, air monitoring, and cleanroom applications.

Q: Where should the Kimo CP 300 Pressure Transmitter be installed?

A: You can install the CP 300 transmitter on a wall or within a duct, using the supplied mounting bracket. Its compact size and robust design allow flexible installation in various industrial environments.

Q: What are the output signal options for this transmitter?

A: The CP 300 offers selectable output options of 0-10V or 4-20mA, accommodating integration with a variety of control systems and monitoring equipment.

Q: When should I select a different scale range for the CP 300 transmitter?

A: If your application requires pressure measurements outside the standard 0 to 1000 Pa range, alternative scale ranges are available to ensure accuracy and suitability for your process needs.

Q: What are the main benefits of using the CP 300 in industrial applications?

A: With its high accuracy (0.5% FS), fast response, flexible outputs, durable construction, and easy calibration, the CP 300 enhances process reliability and simplifies maintenance in HVAC and process control settings.
