HUBA CONTROL Pressure Transmitter Model: 520.914S032401W RANGE 0-1 BAR OUTPUT 4-20mA

Send Inquiry

Request To Call Back

HUBA CONTROL Pressure Transmitter Model: 520.914S032401W RANGE 0-1 BAR OUTPUT 4-20mA

Name: HUBA CONTROL Pressure Transmitter Model: 520.914S032401W RANGE 0-1 BAR OUTPUT 4-20mA
Brand: D. P. ENGINEERS
Price: 10800 INR
Availability: InStock

Price 10800 INR/ Piece

Get a Price/Quote

MOQ : 5 Pieces

HUBA CONTROL Pressure Transmitter Model: 520.914S032401W RANGE 0-1 BAR OUTPUT 4-20mA Specification

Thread
1/4 inch NPT

Outer Size
0 ... 1 BAR

Usage
REFRIGERATION SYSTEMS,CPU,WATER PUMPS,ULTRAFILTRATION SYSTEM

Material
Stainless Steel

Size
0 ... 1 BAR

Processing Type
Standard

Product Type
HUBA CONTROL Pressure Transmitter Model: 520.914S032401W RANGE 0-1 BAR OUTPUT 4-20mA

Weight
150 Grams (g)

Mount Type
Panel

Color
white

Scale Range
0 ... 1 BAR

Accuracy
0.3 %

HUBA CONTROL Pressure Transmitter Model: 520.914S032401W RANGE 0-1 BAR OUTPUT 4-20mA Trade Information

Minimum Order Quantity
5 Pieces

FOB Port
EAST DELHI

Payment Terms
Cash Against Delivery (CAD), Cash on Delivery (COD), Paypal, Cash in Advance (CID), Cash Advance (CA)

Supply Ability
1 Piece Per Day

Delivery Time
1 Days

Main Export Market(s)
Middle East, Asia

Main Domestic Market
All India

About HUBA CONTROL Pressure Transmitter Model: 520.914S032401W RANGE 0-1 BAR OUTPUT 4-20mA

HUBA CONTROLA Pressure Transmitter Model: 520.914S032401W RANGE 0-1 BAR OUTPUT 4-20mA

Relative Pressure TransmitterA

TypeA - 520

ManufacturerA - HUBA CONTROL

ModelA - 520.914S032401W

RANGE -A 0-1 BAR

OUTPUT -A A 4-20mA

TheA A CompactA TypeA 520A PressureA TransmitterA IsA BasedA Upon TheA A HubaA ControlA DevelopedA ThickA FilmA TechnologyA WhereA TheA PressureA Measuring Cell Is Fully Welded.

ThisA A TransmitterA Meets TheA HighA BurstA ProtectionA DemandsA And IsA Suitable For The Use In All Types Of Refrigerants Including Ammonia.

Pressure RangeA

-1 ... 9 bar / 0 ... 2.5 a 1000 bar

Compact,Rugged Construction

Welded Without Sealing parts,No Elastomer Seals

Large Selection Of Connections Available.

Saving Time By Quick Cable Mounting By The Customer With Swift Connector

General Features:

Compact, Rugged Construction
Large Selection Of Connections Available
Welded Without Sealing Parts, No Elastomer Seals
Medium: Liquids, Gases And Refrigerants (Including Ammonia)
Saving Time By Quick Cable Mounting By The Customer With Swift Connector

SERIES	Type 520
PRESSURE RANGE	0 ... 1 BAR
POWER SUPPLY	7 - 33 VDC
OUTPUT DC	4 - 20 mA
ELECTRICAL CONNECTION	M12x1
DESCRIPTION	Pressure Transmitter
PRESSURE CONNECTION	G 1/4
INDEX PROTECTION IP	IP67
ACCURACY	A 0.3 % fs
MEDIUM TEMPERATURE RANGE	-15 ... +125 AC
RESPONSE TIME	< 2 ms, (1 ms typical)
MATERIAL	Connection Stainless Steel 1.4404 / AISI 316L
DIMENSIONS (MM)	24 x 46.7 MM
CONFORMITY	EN 61326-2-3 / IEC 68-2-27 / IEC 68-2-29 / IEC 68-2-6 / UL E325110

WhatsAppNo.9871014210,

WhatsAppNo.9811065204,

WhatsApp No.8376899729,

WhatsApp No.8368888047,

WhatsApp No.9268631221,

Versatile Application in Industrial Systems

The HUBA CONTROL 520.914S032401W Pressure Transmitter efficiently measures pressure in systems handling steam, oil, or gas. Its application covers refrigeration systems, CPU cooling, water pumps, and ultrafiltration plants, proving its adaptability in diverse industrial scenarios. Reliable stainless steel housing and excellent finish options enhance its longevity, even in harsh operating conditions, making it a dependable solution across numerous industries.

High Precision and Robust Build Quality

With an accuracy of 0.3%, this pressure transmitter guarantees exact pressure readings crucial for safety and process optimization. The unit's polished, galvanized, or matte stainless steel casing resists corrosion, supporting continued performance. Weighing just 150 grams, it is lightweight yet sturdy, facilitating secure panel mounting and delivering consistent readings throughout its service life.

FAQ's of HUBA CONTROL Pressure Transmitter Model: 520.914S032401W RANGE 0-1 BAR OUTPUT 4-20mA:

Q: How does the HUBA CONTROL 520.914S032401W pressure transmitter operate?

A: This pressure transmitter transforms differential pressure into a standardized 4-20mA output. It reliably measures pressures from 0 to 1 BAR, making it suitable for applications that require precise control and monitoring.

Q: What industries typically benefit from using this model?

A: Industries such as refrigeration, water treatment, oil and gas, as well as ultrafiltration systems, utilize this transmitter due to its high accuracy and compatibility with various process fluids. Its adaptability also extends to CPU and water pump monitoring.

Q: When should I choose the 520.914S032401W over other pressure transmitters?

A: Choose this model when your application demands a compact, panel-mountable transmitter with excellent accuracy (0.3%), corrosion-resistant stainless steel construction, and a 4-20mA output, especially for pressures within the 0-1 BAR range.

Q: Where is the ideal installation point for this pressure transmitter?

A: The transmitter is best installed on control panels using its panel mount design and 1/4 inch NPT thread, close to the point of pressure measurement for accurate real-time readings.

Q: What is the process for maintaining the pressure transmitter?

A: Maintenance involves periodic inspection for system leaks, cleaning the pressure port, and ensuring electrical connections remain secure. Regular calibration checks are advised to preserve measurement accuracy.

Q: How can the various finish options benefit my application?

A: Available finishes-antique, polished, galvanized, and matte-allow for customization to match your system's aesthetic or environmental conditions, offering both corrosion resistance and a suitable appearance for different settings.

Q: Can this transmitter measure pressure in aggressive environments or fluids?

A: Yes, the stainless steel construction and robust sealing make it suitable for measuring steam, oil, gas, and other challenging media typically found in industrial and process environments.
