GEMTECH DIFFERENTIAL PRESSURE GAUGE FROM Nangla Gujran,Ballbagarh Sohna Road,Sarurpur Industrial Area, Faridabad

About GEMTECH DIFFERENTIAL PRESSURE GAUGE FROM Nangla Gujran,Ballbagarh Sohna Road,Sarurpur Industrial Area, Faridabad

 GEMTECH DIFFERENTIAL PRESSURE GAUGE FROM Nangla Gujran,Ballbagarh Sohna Road,Sarurpur Industrial Area, Faridabad  Series G2000 GEMTECH Differential Pressure Gauges are Widely Utilized For Measuring Pressure of Fan And Blowing Machine, resistance of Filter,Wind Speed, Furnace Pressure, Differential Pressure Of Pore Plate,The Pressure of drum water level,Liquid Amplifier And Hydraulic Pressure System.Meantime,They Are Used To Control The Automatic Valve And Specific Value Of Air-Producer Gas In Combustion And They Are Used To Test Blood Pressure And Respiratory Pressure In Medical Health Care Equipment.There Are More Than 81 Models To Suit Your Needs Precisely.The Key Components Adopt Import Materials.

SPECIFICATION


• Ambient Temperature    -21 140 -6 60
• Rated Pressure -20 inHg30 inHg (-68103KPa)
• Overpressure  Protective rubber stopper will be blown out if rated pressure is up to about 50.8 inHg (172KPa)
• Process Connections  1/83 female NPT duplicate high and low pressure taps one pair side and one pair back
• Housing  Die cast aluminum case and bezel,With acrylic cover, Exterior finish is coated gray to withstand 168 Hour Salt Spray Corrosion Test
• Accuracy  2% of full span at 70 (21 (3% on -0, and 4% on -00)
• Range -20 inHg38 inHg (-68KPa130KPa)(Special Specification also can be ordered.)

FEATURES

• OEM/ODM
• There Is No Need To Fill Liquid To Gauge.
• The Gauge Can Measure Positive Pressure,Negative Pressure And Differential Pressure.
• It Will Be Easy To Install And Measure In Different Ways Because Of Two Groups Of Ports Which Can Measure Positive And Negative Pressure.
• To Eliminate The Friction From The Movement Of Gear Wheel By The Mechanism Of Magnetic Magnet Feed.
• Exact And Stable Fixed Position Of Needle.
• The Gauge Has Great Antiknock Characteristics.
• There Are 81 Types Of Ranges.
• Minimum is 0-60 Pa And Maximum is 0-21-KPa
  PRODUCT APPLICATIONS
• Filter Monitoring
• Air Velocity With Pitot Tube
• Blower Vacuum Monitoring
• Fan Pressure Indication
• Duct,Room or Building Pressures
• Clean Room Positive Pressure Indication
• MODELS & ORDERING

GEMTECH By  Model Number Popularity

• FILTER BY
• Range  MM Of Water

Model	Description
G2000-100MM	GEMTECH DIFFERENTIAL PRESSURE GAUGE,Range 0-100 MM WC Minor Divisions 2.0.
G2000-10MM	GEMTECH DIFFERENTIAL PRESSURE GAUGE,Range 0-10 MM WC Minor Divisions .20,Calibrated For Vertical Scale Position.
G2000-150MM	GEMTECH DIFFERENTIAL PRESSURE GAUGE,Range 0-150 MM WC
G2000-15MM	GEMTECH DIFFERENTIAL PRESSURE GAUGE,Range 0-15 MM WC
G2000-200MM	GEMTECH DIFFERENTIAL PRESSURE GAUGE,Range 0-200 MM WC
G2000-250MM	GEMTECH DIFFERENTIAL PRESSURE GAUGE,Range 0-250 MM WC
G2000-25MM	GEMTECH DIFFERENTIAL PRESSURE GAUGE,Range 0-25 MM WC Minor Divisions .50.
G2000-300MM	GEMTECH DIFFERENTIAL PRESSURE GAUGE,Range 0-300 MM WC
G2000-50MM	GEMTECH DIFFERENTIAL PRESSURE GAUGE,Range 0-50 MM W.C.,Minor Divisions 1.0.
G2000-6MM	GEMTECH DIFFERENTIAL PRESSURE GAUGE,Range 0-6 MM W.C.,Minor Divisions .20,Calibrated For Vertical Scale Position.
G2000-80MM	GEMTECH DIFFERENTIAL PRESSURE GAUGE,Range 0-80 MM W.C.,Minor Divisions 2.0.

Additional Information:

• Item Code:
GEMTECH I DIFFERENTIAL PRESSURE GAUGE FROM Nangla Gujran,Ballbagarh Sohna Road,Sarurpur Industrial Area, Faridabad - 121004
• E-mail :
• dpsharma74@yahoo.co.in,
• dpsharma1974@gmail.com,
• dpsharma949@gmail.com
• Mr D.P.SHARMA 9871014210
• WhatsApp number :9871014210,9268631221
• Websites :
• www.dpengineers.in,
• www.dpengineer.in,
• www.dpengineers.co.in,
• www.dpengineer.co.in,
• www.dpengineerindia.in,
• www.dpengineersindia.net,
• www.dpengineersdelhi.co.in,
• www.dpengineersdelhi.com,
• www.dp-engineers.co.in,
• www.dpengineersdelhi.net,
• WhatsApp No.9871014210,WhatsApp No.9811065204,WhatsApp No.8376899729,WhatsApp No.8368888047,WhatsApp No.9268631221,
•

Versatile Industrial Pressure Monitoring

The GEMTECH Differential Pressure Gauge is engineered for accurate measurement of pressure in industrial and commercial environments. Suitable for a range of applications including hotels, hospitals, power and cement plants, and the food and beverage sector, its durable stainless steel build and choice of finishes ensure longevity and compatibility with demanding environments. It supports back mounting for easy installation and offers a clear analog display for quick readings.


Robust Construction and Reliable Performance

Manufactured in Faridabad's Sarurpur Industrial Area, this gauge combines a sturdy 4-inch stainless steel body with a precision plastic dial and aluminum pointer. The back mount design and threaded 1/8-inch connection enable seamless integration into existing systems. Multiple scale options and finishes provide the flexibility required by exporters, manufacturers, and traders across India and beyond.
