GEMTECH Diff Pressure Gauge Distributor Form Tala Nagari Aligarh(UP)

About GEMTECH Diff Pressure Gauge Distributor Form Tala Nagari Aligarh(UP)

GEMTECH Diff Pressure Gauge Distributor Form Tala Nagari Aligarh(UP)

Series G2000A GEMTECHA Differential Pressure GaugesA are Widely Utilized For Measuring Pressure of Fan And Blowing Machine,resistance of Filter, Wind Speed, Furnace Pressure, Differential Pressure Of Pore Plate,The Pressure of drum water level, Liquid Amplifier And Hydraulic Pressure System.Meantime,They Are Used To Control The Automatic Valve And Specific Value Of Air-Producer Gas In Combustion And They Are Used To Test Blood Pressure And Respiratory Pressure In Medical Health Care Equipment.There Are More Than 81 Models To Suit Your Needs Precisely.The Key Components Adopt Import Materials.
SPECIFICATION

• Ambient TemperatureA -A A -21 ~140 -6 ~60

• Rated PressureA -20 inHg~30 inHg (-68~103KPa)

• Overpressure -A Protective rubber stopper will be blown out if rated pressure is up to about 50.8 inHg (172KPa)

• Process Connections -A 1/8" female NPT duplicate high and low pressure taps - one pair side and one pair back

• HousingA - Die cast aluminum case and bezel,with acrylic cover, Exterior finish is coated gray to withstandA 168 Hour Salt Spray Corrosion Test

• AccuracyA - A2% of full span at 70 21 3% on -0, and A4% on -00)

• RangeA -20 inHg~38 inHg (-68KPa~130KPa)(Special Specification also can be ordered.)

FEATURES

• OEM/ODM
• There Is No Need To Fill Liquid To Gauge.
• The Gauge Can Measure Positive Pressure,Negative Pressure And Differential Pressure.
• It Will Be Easy To Install And Measure In Different Ways Because Of Two Groups Of Ports Which Can Measure Positive AndA Negative Pressure.
• To Eliminate The Friction From The Movement Of Gear Wheel By The Mechanism Of Magnetic Magnet Feed.
• Exact And Stable Fixed Position Of Needle.
• The Gauge Has Great Antiknock Characteristics.
• There Are 81 Types Of Ranges.Minimum is 0-60 Pa And Maximum is 0-21-KPa

PRODUCT APPLICATIONS

• Filter Monitoring
• Air Velocity With Pitot Tube
• Blower Vacuum Monitoring
• Fan Pressure Indication
• Duct,Room or Building Pressures
• Clean Room Positive Pressure Indication

MODELS & ORDERING



GEMTECH ByA A Model NumberA PopularityA

• FILTER BY
• Range -A MM Of Water

Model	Description
G2000-100MM	DPG,Range 0-100 MM W.C., Minor Divisions 2.0.
G2000-10MM	DPG,RangeA 0-10 MM W.C.,Minor DivisionsA .20,Calibrated For Vertical Scale Position.
G2000-150MM	DPG,RangeA 0-150 MM W.C.
G2000-15MM	DPG,Range 0-15 MM W.C.
G2000-200MM	DPG,Range 0-200 MM W.C.
G2000-250MM	DPG,Range 0-250 MM W.C.
G2000-25MM	DPG,RangeA 0-25 MM W.C. Minor Divisions .50.
G2000-300MM	DPG,RangeA 0-300 MM W.C.
G2000-50MM	DPG,RangeA 0-50 MM W.C., Minor Divisions 1.0.
G2000-6MM	DPG,RangeA 0-6 MM W.C., Minor Divisions .20, Calibrated For Vertical Scale Position.
G2000-80MM	DPG,RangeA 0-80 MM W.C., Minor Divisions 2.0.

Versatile Industrial Compatibility

Designed for demanding settings, the GEMTECH Diff Pressure Gauge supports a broad range of industries such as pharmaceuticals, hotels, hospitals (including operation theaters), malls, power, cement, steel, fertilizer, textile, and more. Its robust construction and adaptability make it a reliable choice for multiple applications.


Precision Measurement & Durability

Constructed with an aluminum pointer and metal alloy body, this pressure gauge promises both longevity and accurate performance. The 2% full-span accuracy at standard room temperature ensures confidence in readings, while the analog display delivers clear and immediate results. Its varied finish options fit diverse operational aesthetics.


User-Friendly Installation and Operation

Featuring a 4-inch dial, multiple pressure tap configurations (side and back), and back mounting, the gauge is engineered for straightforward installation. Compatible with standard 1/8" female NPT threads, it integrates seamlessly into existing processes, reducing downtime and ensuring efficient setup.
