Dwyer USA Magnehelic Gauges 0 To 10 Inch WC

Get a Price/Quote

MOQ : 25 Pieces

Dwyer USA Magnehelic Gauges 0 To 10 Inch WC Specification

Grade
Industrial Grade

Outer Size
4 inch Diameter Case

Thread
1/8 NPT

Display
Analog Dial

Sensor Type
Diaphragm

Seal Material
Silicone Rubber

Material
Die-cast Aluminum Case, Acrylic Lens

Dial Material
White Aluminum with Black Graduations

Pointer Material
Aluminum

Processing Type
Die Cast and Machined

Diameter
4 inches

Glass Size
Full View Clear Acrylic Lens

Mount Type
Flush or Surface Mount

Scale Range
0 to 10 Inch WC (Water Column)

Accuracy
2% of Full Scale

Accessories
Surface Mounting Bracket, Two Static Pressure Tips, Screw Pack, Rubber Gasket

Overpressure Limit
15 psi Maximum

Connection Location
Back and Side Ports

Mounting Orientation
Vertical

Model Number
2000-10

Compliance
RoHS Compliant

Operating Temperature
-7C to 60C (20F to 140F)

Zero Adjustment
External Adjustment Knob

Weight
400 grams (approx.)

Dwyer USA Magnehelic Gauges 0 To 10 Inch WC Trade Information

Minimum Order Quantity
25 Pieces

FOB Port
Delhi

Payment Terms
Cash on Delivery (COD), Paypal, Cash in Advance (CID), Cash Advance (CA), Cash Against Delivery (CAD)

Supply Ability
1 Piece Per Day

Delivery Time
1 Days

Sample Available
No

Main Export Market(s)
Middle East, Asia

Main Domestic Market
All India

Dwyer USA Magnehelic Gauges 0 To 10 Inch WC About

Dwyer USA Magnehelic Gauges 0 To 10 Inch WC

Model	Description
2010	Differential pressure gage, range 0-10" w.c., minor divisions .20.

The industry standard in indicating low air or gas pressures of positive, negative, or differential pressures.

Large, easy-to-read 4" (102 mm) dial.

No manometer fluid to evaporate, freeze, or cause toxic or leveling problems.

INCLUDES

Two 1/8" NPT plugs, two 1/8" rubber tubing adapters, and three mounting adapters with screws

MORE ABOUT THIS ITEM

The Magnahelic guage is the industry standard to measure fan and blower pressures, filter resistance, air velocity, furnace draft, pressure drop across orifice plates, liquid levels with bubbler systems, and pressures in fluid amplifier or fluidic systems. The gauge's motion is damped with high-viscosity silicone fluid. The zero adjustment screw is conveniently located in the plastic cover, and is accessible without removing the cover. O-ring seal provides pressure tightness. Rugged design resists shock, vibration, and overpressure.

The helix is precision-made from an alloy of high magnetic permeability. Mounted in jeweled bearings, it turns freely, following the maganetic field to move the pointer across the scale. The samarium cobalt magnet is mounted at one end of the range spring and rotates the helix without mechanical linkages.

Specifications & Description

Accuracy	3% full-scale
Dial Size (in)	4
Dial Size (mm)	102
Min Pressure (in WC)	0
Max Pressure (in WC)	0.5
Min Temperature ( F)	20
Max Temperature ( F)	140
Min Temperature ( C)	7
Max Temperature ( C)	60
Liquid Fill	Silicone
Case	Aluminum
Lens Material	Polycarbonate
Process Connection	1/8" NPT(F)
Unit Of Measurement	" WC
Display	analog dial
Media Compatibility	Air and noncombustible, compatible gases
Description	Magnehelic Differential Pressure Gauge, 2010: 0-10" w.c

Accurate Differential Pressure Monitoring

This Magnehelic gauge provides dependable measurement with 2% full-scale accuracy, making it ideal for monitoring air or fluid pressures in HVAC, filtration, or process control environments. The durable acrylic full-view lens and white aluminum dial enhance visibility and reliability in industrial settings.

Robust Construction and Versatile Installation

Manufactured with a die-cast aluminum case and silicone rubber seals, this gauge is built to endure harsh conditions. Its vertical mounting orientation and multiple port locations (back and side) allow for both flush or surface installation, while supplied accessories streamline setup.

FAQ's of Dwyer USA Magnehelic Gauges 0 To 10 Inch WC:

Q: How do I install the Dwyer Magnehelic Gauge Model 2000-10?

A: The gauge can be installed vertically using the included surface mounting bracket or flush mounted with supplied screws. It features both back and side 1/8 NPT connection ports for flexible plumbing. Ensure that the ports are properly sealed using the provided rubber gasket for optimal performance.

Q: What substances can the Magnehelic Gauge safely measure?

A: This gauge is engineered to measure the differential pressure of steam, gas, or oil, making it suitable for a wide range of industrial applications, including HVAC systems, clean rooms, and process lines.

Q: When should I use the zero adjustment knob?

A: Use the external zero adjustment knob whenever you need to recalibrate the gauge to ensure the pointer reads zero when both pressure connections are open to atmospheric pressure before starting a new measurement or after maintenance.

Q: Where are the connection ports located on this gauge?

A: The Model 2000-10 offers connection ports on both the back and side of the unit, allowing for versatile installation in various equipment configurations or tight spaces.

Q: What is the maximum operating temperature and overpressure limit?

A: This gauge operates reliably from -7C to 60C (20F to 140F) and can withstand overpressures up to 15 psi, ensuring durability and safety in demanding industrial environments.

Q: How does the Magnehelic Gauge benefit industrial processes?

A: With its high accuracy, durable construction, and clear analog display, the gauge provides quick and precise pressure readings, facilitating efficient monitoring and maintenance of systems, ultimately helping maintain process safety and equipment longevity.
