Dwyer Maghnehic Differential Gauge in Petrochemical Industry

About Dwyer Maghnehic Differential Gauge in Petrochemical Industry

Dwyer Maghnehic Differential Gauge in Petrochemical Industry

SERIES 2000 MAGNEHELICA DIFFERENTIAL PRESSURE GAGES Indicate Positive, Negative or Differential, Accurate within 1%

• No Power Required
• Low Cost
• Used in Isolation/ Hospital Environments and Temporary Units (no power required)

Select the Series 2000 MagnehelicA Gage for a versatile low differential pressure gage with a wide choice of 81 models and 27 options to choose from. Using Dwyeras simple, frictionless MagnehelicA gage movement, it quickly indicates air or noncorrosive gas pressures--either positive, negative (vacuum) or differential. The design resists shock, vibration, over-pressures and is weatherproof to IP67. Select the -HA High Accuracy MagnehelicA Gage option for an accuracy within 1% of full scale, located below in the Product Configurator. Also included with the aHA option at no extra cost are a mirrored scale overlay and a 6 point calibration certificate.

NIST CALIBRATION available in Product Configurator.

Note: May be used with Hydrogen. Order a Buna-N diaphragm. Pressures must be less than 35 psi.

Please see Series AT-2000 for ATEX approved.
California Residents:  Click Here for Proposition 65 WARNING.

PRODUCT APPLICATIONS

• Filter Monitoring
• Air Velocity with Dwyer Pitot Tube
• Blower Vacuum Monitoring
• Fan Pressure Indication
• Duct, Room or Building Pressures
• Clean Room Positive Pressure Indication

Model	Description
2000-1.5KPA	Differential Pressure Gage, Range 0-1.5 kPa, minor divisions .05.
2000-10KPA	Differential Pressure Gage, Range 0-10 kPa, minor divisions .20.
2000-15KPA	Differential Pressure Gage, Range 0-15 kPa, minor divisions .50.
2000-1KPA	Differential Pressure Gage, Range 0-1 kPa, minor divisions .02.
2000-20KPA	Differential Pressure Gage, Range 0-20 kPa, minor divisions .50.
2000-25KPA	Differential Pressure Gage, Range 0-25 kPa, minor divisions .50.
2000-2KPA	Differential Pressure Gage, Range 0-2 kPa, minor divisions .05.
2000-30KPA	Differential Pressure Gage, Range 0-30 kPa, minor divisions 1.0.
2000-3KPA	Differential Pressure Gage, Range 0-3 kPa, minor divisions .10.
2000-4KPA	Differential Pressure Gage, Range 0-4 kPa, minor divisions .10.
2000-5KPA	Differential Pressure Gage, Range 0-5 kPa, minor divisions .10.
2000-8KPA	Differential Pressure Gage, Range 0-8 kPa, minor divisions .20.
2300-1KPA	Differential Pressure Gage, Range 0.5-0-0.5 kPa, minor divisions .02.
2300-3KPA	Differential Pressure Gage, Range 1.5-0-1.5 kPa, minor divisions .10.

Superior Accuracy and Versatility

Engineered for accuracy within 2% of full span, the Dwyer Magnehelic Gauge is suitable for critical operations in petrochemical environments. Its broad scale range and ability to measure various media, such as steam, oil, and gas, make it a versatile choice for monitoring and control.


Durable Build for Industrial Demands

With a metal alloy body, anti-corrosive surface finishes, and an aluminum pointer, this gauge withstands rigorous industrial use. The robust construction guarantees long service life in challenging conditions, from power plants to pharmaceutical facilities, ensuring your investments are protected.


User-Friendly and Easy Installation

The standard back mount allows for seamless installation in control panels or equipment. Its analog display and clear dial markings make pressure readings instantly accessible, enabling efficient monitoring by technical and non-technical personnel alike.
