Differential Pressure Transmitter

Price 26800 INR/ Piece

Get a Price/Quote

MOQ : 25 Pieces

Differential Pressure Transmitter Specification

Bourdon Tube
Stainless Steel Bourdon Tube

Sensor Type
Piezoresistive

Seal Material
PTFE

Display
Digital

Grade
Industrial Grade

Outer Size
120mm

Thread
1/4 NPT Male

Material
Stainless Steel

Dial Material
Aluminum

Pointer Material
Black Anodized Aluminum

Processing Type
Precision Machined

Diameter
100 mm

Glass Size
100 mm

Mount Type
Panel Mount

Scale Range
0-250 mbar

Accuracy
0.5% F.S.

Accessories
Mounting Bracket, User Manual

Explosion Proof
Available on Request

Output Signal
4-20 mA

Ingress Protection
IP65

Weight
1.2 kg

Operating Temperature Range
-20C to +80C

Electrical Connection
M12 Connector

Response Time
<100 ms

Compliance
CE, RoHS

Overpressure Limit
2x Full Scale

Power Supply
24V DC

Differential Pressure Transmitter Trade Information

Minimum Order Quantity
25 Pieces

FOB Port
Delhi

Payment Terms
Cash in Advance (CID), Cash Against Delivery (CAD), Cash Advance (CA), Paypal, Cash on Delivery (COD)

Supply Ability
1 Piece Per Day

Delivery Time
1 Days

Main Export Market(s)
Middle East, Asia

Main Domestic Market
All India

About Differential Pressure Transmitter

Differential Pressure Transmitter

Differential pressure transmitter from Beck Gmbh 984m series are used for measuring differential pressure, positive pressure and vacuum pressure. These sensor offer 2 pressure ranges which can be alternatively be selected by a jumper for monitoring gases, clean air and non-aggressive media.

Application:

Air conditioning and clean rooms
Building automation
Environment protection
fans and blower control
valve and flap control
filter and blower monitoring
stair pressurisation
control of air flows
Air flow monitoring
Air velocity measurement
Gas Flow measurement
Gas flow metering

Features:

Dual jumper selectable measuring range measuring range: 0-100Pa to 0-250kPa with or without display
4-20mA, 0-10V jumper selectable output square rooted function output
IP54, IP65 housing 2, 3 wire connection
Eg. 984m.535 0-1kPA/ 0-2.5 kPa

Rugged, Precise Measurement in Demanding Environments

Engineered for industrial use, this differential pressure transmitter excels in precision with its 0.5% full-scale accuracy and fast response. Stainless steel construction and IP65 ingress protection make it ideal for harsh workplaces involving liquid, gas, or steam. Its panel-mount design, PTFE sealing, and the robust 1/4 NPT male thread facilitate hassle-free installation and long-term durability.

User-Friendly Digital Display & Simple Setup

Equipped with a clear digital display and M12 connector, this transmitter ensures hassle-free wiring and quick status readings. The package includes a mounting bracket and a comprehensive user manual, supporting efficient setup and reducing downtime during installation.

FAQ's of Differential Pressure Transmitter:

Q: How do I install the differential pressure transmitter in my industrial setup?

A: Begin by securely mounting the transmitter on a panel using the included mounting bracket. Make fluidic connections through the 1/4 NPT male thread, ensuring a proper seal with PTFE. Proceed to connect the 24V DC power supply via the M12 connector, refer to the user manual for detailed wiring diagrams, and check the display for correct readings.

Q: What substances can this transmitter measure pressure of?

A: This device is suitable for monitoring the differential pressures of liquids, gases, and steam, making it versatile for various industrial processes involving these mediums.

Q: When should I consider requesting the explosion-proof option?

A: Choose the explosion-proof certified model if you plan to deploy the transmitter in hazardous or potentially explosive environments such as chemical plants or oil and gas facilities. This ensures compliance with safety standards in such locations.

Q: Where is the best mounting location for accurate measurements?

A: Install the transmitter in a location that is vibration-free, within the recommended operating temperature range of -20C to +80C, and easily accessible for maintenance. Proper site selection enhances measurement consistency and facilitates monitoring.

Q: What are the main benefits of this transmitter's digital display and fast response time?

A: The digital display enables real-time, precise pressure readings at a glance, while the response time of less than 100 ms ensures rapid detection and reporting of pressure changes, ideal for dynamic processes.

Q: How does this transmitter ensure longevity and reliability in tough conditions?

A: Its IP65 ingress protection, powder-coated stainless steel housing, PTFE seal, and RoHS/CE compliance collectively safeguard the device from dust, moisture, and corrosive substances, delivering resilient and safe operation in demanding industrial environments.
