Differential Pressure Gauge GEMTECH MAKE Wholesale by Udyog Vihar

Send Inquiry

Request To Call Back

Differential Pressure Gauge GEMTECH MAKE Wholesale by Udyog Vihar

Get a Price/Quote

MOQ : 50 Pieces

Differential Pressure Gauge GEMTECH MAKE Wholesale by Udyog Vihar Specification

Outer Size
4 inch / 100 mm

Display
Analog

Thread
1/8" female NPT duplicate high and low pressure taps - one pair side and one pair back

Usage
pharmaceutical,Hotel,Malls,Hospital,OT,POWER PLANT,CEMENT PLANT,STEEL PLANT,FERTILIZER,TEXTILE,Pharmaceutical Manufacture,Food And Beverages Industry,Pulp And Paper Industry,Textile Industry

Material
Metal Alloy

Dial Material
Plastic

Pointer Material
Aluminum

Size
4 inch / 100 mm

Processing Type
Standard

Product Type
Differential Pressure Gauge GEMTECH MAKE Wholesale by Udyog Vihar

Diameter
4 inch / 100 Millimeter (mm)

Weight
550 Grams (g)

Mount Type
Back

Color
Black

Scale Range
MM WC/ CM / PAC / KPA / INCH / PSI

Accuracy
2% of full span at 70 21 3% on -0, and 4% on -00) %

Differential Pressure Gauge GEMTECH MAKE Wholesale by Udyog Vihar Trade Information

Minimum Order Quantity
50 Pieces

FOB Port
Delhi

Payment Terms
Cash on Delivery (COD), Cash in Advance (CID), Cash Advance (CA), Paypal, Cash Against Delivery (CAD)

Supply Ability
1 Piece Per Day

Delivery Time
1 Days

Main Export Market(s)
Asia, Middle East

Main Domestic Market
All India

About Differential Pressure Gauge GEMTECH MAKE Wholesale by Udyog Vihar

GEMTECH Differential Pressure Gauge From Ghiloth Industrial Area Neemrana Rajasthan India

Differential Pressure Gauge GEMTECH MAKE Wholesale by Udyog Vihar
Series G2000 GEMTECH Differential Pressure Gauges are Widely Utilized For Measuring Pressure of Fan And Blowing Machine, resistance of Filter,Wind Speed, Furnace Pressure, Differential Pressure Of Pore Plate,The Pressure of drum water level,Liquid Amplifier And Hydraulic Pressure System.Meantime,They Are Used To Control The Automatic Valve And Specific Value Of Air-Producer Gas In Combustion And They Are Used To Test Blood Pressure And Respiratory Pressure In Medical Health Care Equipment. There Are More Than 81 Models To Suit Your Needs Precisely.The Key Components Adopt Import Materials.
SPECIFICATION

Ambient Temperature - -21 ~140 -6 ~60

Rated Pressure -20 inHg~30 inHg (-68~103KPa)

Overpressure - Protective rubber stopper will be blown out if rated pressure is up to about 50.8 inHg (172KPa)

Process Connections - 1/8" female NPT duplicate high and low pressure taps - one pair side and one pair back

Housing - Die cast aluminum case and bezel,with acrylic cover, Exterior finish is coated gray to withstand 168 Hour Salt Spray Corrosion Test

Accuracy - A2% of full span at 70 (21 (A3% on -0,and A4% on -00)

Range -20 inHg~38 inHg (-68KPa~130KPa)(Special Specification also can be ordered.)

FEATURES

OEM/ODM
There Is No Need To Fill Liquid To Gauge.
The Gauge Can Measure Positive Pressure,Negative Pressure And Differential Pressure.
It Will Be Easy To Install And Measure In Different Ways Because Of Two Groups Of Ports Which Can Measure Positive And Negative Pressure.
To Eliminate The Friction From The Movement Of Gear Wheel By The Mechanism Of Magnetic Magnet Feed.
Exact And Stable Fixed Position Of Needle.
The Gauge Has Great Antiknock Characteristics.
There Are 81 Types Of Ranges.Minimum is 0-60 Pa And Maximum is 0-21-KPa

PRODUCT APPLICATIONS

Filter Monitoring
Air Velocity With Pitot Tube
Blower Vacuum Monitoring
Fan Pressure Indication
Duct,Room or Building Pressures
Clean Room Positive Pressure Indication

MODELS & ORDERING

GEMTECH By Model Number Popularity

FILTER BY
Range - MM Of Water

Model	Description
G2000-100MM	DPG,Range 0-100 MM W.C., Minor Divisions 2.0.
G2000-10MM	DPG,Range 0-10 MM W.C.,Minor Divisions .20,Calibrated For Vertical Scale Position.
G2000-150MM	DPG,Range 0-150 MM W.C.
G2000-15MM	DPG,Range 0-15 MM W.C.
G2000-200MM	DPG,Range 0-200 MM W.C.
G2000-250MM	DPG,Range 0-250 MM W.C.
G2000-25MM	DPG,Range 0-25 MM W.C. Minor Divisions .50.
G2000-300MM	DPG,Range 0-300 MM W.C.
G2000-50MM	DPG,Range 0-50 MM W.C., Minor Divisions 1.0.
G2000-6MM	DPG,Range 0-6 MM W.C., Minor Divisions .20, Calibrated For Vertical Scale Position.
G2000-80MM	DPG,Range 0-80 MM W.C., Minor Divisions 2.0.

Versatile Scale and High Accuracy

This pressure gauge covers multiple measurement units, including MM WC, KPA, and PSI, which allows precise readings in varied industrial environments. Its accuracy range (2% or 4%) suits processes where dependable data is essential.

Robust Build for Demanding Applications

Constructed from a durable metal alloy with a plastic dial and aluminum pointer, the gauge withstands challenging conditions in sectors like pharmaceuticals, textiles, and power plants. The range of finishes, from antique to galvanized, meets both aesthetic and functional requirements.

FAQ's of Differential Pressure Gauge GEMTECH MAKE Wholesale by Udyog Vihar:

Q: How is the Differential Pressure Gauge GEMTECH MAKE installed?

A: The gauge features 1/8" female NPT threaded connections with duplicate pressure taps on both the side and the back, allowing flexible mounting options. With its back-mount design, it can be easily fitted to various panels or surfaces as required in your installation environment.

Q: What types of media can this pressure gauge measure?

A: This differential pressure gauge is suitable for measuring the differential pressure of steam, oil, and gas, making it applicable to a wide range of industrial systems including the food and beverages, textiles, cement, and power plant industries.

Q: When should the gauge be used in process monitoring?

A: It should be used whenever precise monitoring of pressure differences is critical for system performance, such as in pharmaceutical manufacturing, hospital operations, or energy production, ensuring equipment safety and process efficiency.

Q: Where can this gauge be applied in industrial environments?

A: The device finds application across diverse settings like hospitals, hotels, malls, OT, power and cement plants, steel and fertilizer manufacturing units, as well as the food, textile, and pulp and paper sectors.

Q: What is the process for reading the gauge accurately?

A: Simply observe the analog dial, which provides clear readings in multiple scales (MM WC, CM, PSI, etc.) via an aluminum pointer. Ensure the device is installed as per recommended instructions for best accuracy, within 2% to 4% of full scale.

Q: What are the benefits of using this differential pressure gauge?

A: This gauge delivers reliable accuracy, robust construction, and versatile installation options, supporting a variety of scale measurements. It helps maintain process safety and efficiency by providing timely alerts to possible system imbalances.

Q: Is this gauge suitable for use in export and manufacturing operations?

A: Yes, as an exporter, manufacturer, supplier, and trader in India, Udyog Vihar offers this gauge to meet international standards, making it suitable for both domestic and export applications in a range of industries.
