Magnehelic Gauge SS BOX

Price 1500 INR/ Piece

Get a Price/Quote

MOQ : 25 Pieces

Magnehelic Gauge SS BOX Specification

Outer Size
Approximately 120mm x 120mm

Display
Analog

Grade
Industrial-grade

Sensor Type
Differential pressure sensor

Material
Stainless Steel housing

Dial Material
Aluminum with baked enamel finish

Pointer Material
Aluminum

Processing Type
Mechanical

Diameter
4 inches (102mm)

Glass Size
Clear acrylic lens

Mount Type
Surface mounting

Scale Range
0-60 Pascals (custom ranges available)

Accuracy
2% of full scale

Finishing
Stainless Steel Box

Measure Pressure Of
Low differential pressure in HVAC systems

Accessories
Standard SS mounting box

About Magnehelic Gauge SS BOX

Magnehelic Gauge SS BOX

Magnehelic Gauge SS BOX SS-304, SS-202, stainless steel hinged box has a polished satin finish. This box has a hinged door with a face cutout to accept a Dwyer magnehelic pressure guage. Box comes complete with holes to accept pressure differential sensors. Box is fabricated with a flanged face for recess mounting.

Precision in Low Differential Pressure Measurement

Engineered for HVAC systems, the Magnehelic Gauge SS BOX excels in monitoring low differential pressure with an accuracy of 2% of full scale. Its analog display and mechanical processing ensure reliable and immediate readings, ideal for maintaining optimal airflow and safety in industrial environments.

Durable Design for Industrial Settings

Constructed with a stainless steel housing and finished in a steel box, this gauge withstands harsh conditions common in industrial spaces. The aluminum pointer and dial, along with a clear acrylic lens, combine durability with readability, making it suitable for long-term commercial use.

FAQ's of Magnehelic Gauge SS BOX:

Q: How do you install the Magnehelic Gauge SS BOX?

A: Installation is simple with the included stainless steel surface mounting box. Secure the gauge to a flat surface near the area you want to monitor using standard tools. Detailed installation instructions are provided by the manufacturer.

Q: What types of pressure measurements can this gauge perform?

A: It is specially designed to measure low differential pressure, typically found in HVAC systems. Standard scale ranges are 0-60 Pascals, with custom ranges available to cater to different application needs.

Q: When should you use a Magnehelic Gauge in your HVAC system?

A: This gauge is ideal whenever accurate monitoring of low differential pressure is required, such as in cleanrooms, filter monitoring, and ventilation system balancing, for ensuring system efficiency and indoor air quality.

Q: Where can the Magnehelic Gauge SS BOX be mounted?

A: The device is intended for surface mounting, making it versatile for installation on walls, control panels, or any flat surface within industrial and commercial spaces.

Q: What is the process for reading the gauge?

A: Simply observe the aluminum pointer against the analog dial through the clear acrylic lens. The reading corresponds to the measured differential pressure, displayed in Pascals or the selected custom unit.

Q: What are the benefits of using this gauge in industrial settings?

A: Its robust stainless steel construction, high accuracy, and clear analog display make it a reliable choice for continuous pressure monitoring. This helps maintain optimal performance, safety, and compliance in critical HVAC installations.
