Wholesale GEMTECH Differential Pressure Gauges - Ahmedabad

About Wholesale GEMTECH Differential Pressure Gauges - Ahmedabad

• Ambient Temperature -   -21 ~140 -6 ~60

• Rated Pressure -20 inHg~30 inHg (-68~103KPa)

• Overpressure - Protective rubber stopper will be blown out if rated pressure is up to about 50.8 inHg (172KPa)

• Process Connections - 1/8" female NPT duplicate high and low pressure taps - one pair side and one pair back

• Housing - Die cast aluminum case and bezel, with acrylic cover, Exterior finish is coated gray to withstand 168 Hour Salt Spray Corrosion Test

• Accuracy - A2% of full span at 70(21(A3% on -0, and A4% on -00)

• Range -20 inHg~38 inHg (-68KPa~130KPa)(Special Specification also can be ordered.)

• OEM/ODM
• There Is No Need To Fill Liquid To Gauge.
• The Gauge Can Measure Positive Pressure,Negative Pressure And Differential Pressure.
• It Will Be Easy To Install And Measure In Different Ways Because Of Two Groups Of Ports Which Can Measure Positive And Negative Pressure.
• To Eliminate The Friction From The Movement Of Gear Wheel By The Mechanism Of Magnetic Magnet Feed.
• Exact And Stable Fixed Position Of Needle.
• The Gauge Has Great Antiknock Characteristics.
• There Are 81 Types Of Ranges.Minimum is 0-60 Pa And Maximum is 0-21-KPa

• Filter Monitoring
• Air Velocity With Pitot Tube
• Blower Vacuum Monitoring
• Fan Pressure Indication
• Duct,Room or Building Pressures
• Clean Room Positive Pressure Indication

MODELS & ORDERING

GEMTECH By  Model Number Popularity FILTER BY

• Range - MM Of Water

Model	Description
G2000-100MM	DPG,Range 0-100 MM W.C., Minor Divisions 2.0.
G2000-10MM	DPG,Range 0-10 MM W.C.,Minor Divisions .20,Calibrated For Vertical Scale Position.
G2000-150MM	DPG,Range 0-150 MM W.C.
G2000-15MM	DPG,Range 0-15 MM W.C.
G2000-200MM	DPG,Range 0-200 MM W.C.
G2000-250MM	DPG,Range 0-250 MM W.C.
G2000-25MM	DPG,Range 0-25 MM W.C. Minor Divisions .50.
G2000-300MM	DPG,Range 0-300 MM W.C.
G2000-50MM	DPG,Range 0-50 MM W.C., Minor Divisions 1.0.
G2000-6MM	DPG,Range 0-6 MM W.C., Minor Divisions .20, Calibrated For Vertical Scale Position.
G2000-80MM	DPG,Range 0-80 MM W.C., Minor Divisions 2.0.

Reliable Differential Pressure Measurement

GEMTECH Differential Pressure Gauges deliver trustworthy analog readings, ensuring accurate monitoring and control in critical industrial settings. Designed with robustness and reliability in mind, the gauge employs metal alloy construction coupled with a clear, black plastic dial for superior visibility and durability. This makes it an ideal choice for industries requiring stringent pressure monitoring, maximizing both safety and efficiency.


Widely Applicable for Multiple Industries

Our differential pressure gauge stands out for its versatile use across diverse sectors. Whether monitoring cleanroom conditions in pharmaceutical manufacturing, controlling air flow in hospitals and hotels, or optimizing processes in power plants, steel, cement, fertilizer, textile, and food industries, this gauge delivers consistent performance. Its lightweight design and multiple mounting and finishing options suit various installation requirements.

FAQ's of Wholesale GEMTECH Differential Pressure Gauges - Ahmedabad:

Q: How does the GEMTECH Differential Pressure Gauge operate in industrial environments?

A: The GEMTECH Differential Pressure Gauge utilizes an analog display to measure the difference in pressure between two points, making it effective for process control in environments such as steam, oil, or gas pipelines. Its accuracy and durable metal alloy construction ensure reliable readings under industrial conditions.

Q: What types of industries can benefit from using this differential pressure gauge?

A: This gauge is suitable for a broad spectrum of industries, including pharmaceuticals, hospitals, hotels, malls, power plants, cement and steel manufacturing, fertilizer production, textiles, food and beverages, and the pulp and paper industry. Its versatility is supported by the robust build and adaptability to various environments.

Q: When should this differential pressure gauge be calibrated or maintained?

A: Regular calibration is recommended based on industry standards or at intervals specified in your facility's maintenance schedule. This ensures the accuracy of 2% of the full span is consistently upheld, especially crucial in regulated environments like pharmaceuticals and hospitals.

Q: Where is the appropriate location to mount this gauge for optimal performance?

A: The back mount design allows for secure placement on control panels or equipment surfaces. For best results, install the gauge at eye level in a location that minimizes vibration and is easily accessible for inspection and calibration.

Q: What is the process for installing the GEMTECH Differential Pressure Gauge?

A: Installation involves securely mounting the gauge using the back mount fitting on a stable surface, connecting the pressure ports to their respective points, and ensuring tight seals to avoid leaks. Follow manufacturer guidelines to maintain measurement accuracy and device longevity.

Q: How can users benefit from using this differential pressure gauge in critical applications?

A: Users benefit from enhanced process safety, improved operational efficiency, and reduced risk of pressure-related failures. The high accuracy, clear analog display, and resilience against industrial environments facilitate proactive monitoring and quick response in critical applications.
